Beauty Design with low noise and fuel consumption;
Economical, Convient operation, Easy maintain.,
Can be used in office, shop, house, travelling, fan place, restaurant and other places
Packing Dimension: 380X315X330
Rated AC Output: 0.45KW/0.65KW
Max. AC Output: 0.5KW/0.8KW
Rated AC Voltage: 220, 110, 220/110
Fuel Tank Capacity: 4.2 L
Engine Type: Forced air-cooled 2 stroke OHV single cyliner
Phase: Sigle Phase
Frequency: 50 Hz/60Hz
Export Markets: Global
|
Engine |
Model |
GG650 |
GG950 |
|
Model |
1E45F |
1E45F |
|
Type |
Forced air-cooled 2-stroke OHV single cyliner |
|
Displacement(ml) |
63 |
63 |
|
Max output(hp/rpm) |
2/3600 |
2/3600 |
|
Ignition System |
C.D.I. |
C.D.I. |
|
Starting System |
Recoil and manual-operated |
|
Fuel Tank Capacity(I) |
4.2 |
4.2 |
|
Fuel Consumption(l/h) |
0.67 |
0.67 |
|
Continuous Operating Hours(h) |
6.3 |
6.3 |
|
Engine Oil Capacity |
0.4 |
0.4 |
|
Operating Noise at 7m(db) |
57 |
57 |
|
Generator |
Phase Number |
Single phase |
Single phase |
|
Rated Frequency(hz) |
50/60 |
50/60 |
|
Rated Voltage(v) |
220/110 |
220/110 |
|
Power Factor |
1 |
1 |
|
Rated Output(kw) |
0.45 |
0.65 |
|
Max AC Output(kw) |
0.5 |
0.8 |
|
DC Output in Low Voltage |
12V,8.3A |
12V,8.3A |
|
Packing |
Dimension LxWxH(mm) |
380x315x330 |
380x315x330 |
|
Carton |
Brown Carton |
Brown Carton |
|
N.W./G.W(kg) |
15/17 |
18.5/20.5 |
Cotile is in the line of Generator Set, Diesel generators, Diesel generator set, Gasoline generators, Water pump, Pressure washers from 2006.
Our factory has passed ISO9001, CE, EPA, GS, Standard of Europe letting certificate.
More than 95% of the products were exported to America, Middle-east, Southeast Asia, European Union, South America and Africa, etc.
Cotile promise to provide customers with high quality product at best competitive price.
Cotile takes the overseas markets as the most important part for development.
Cotile, your best partner for mutual benefits.
