A compact and light portable power for recreation emergency and home use.
Compact, light weight air-cooled 4-stroke gasoline engines.
Start easily with a light pull.
Large-Capacity Fuel Tank(12 and 22 liters)give a longer power supply.
Economical, low fuel consumption.
Overload protector for safe running.
Easy maintenance with brushless alternator electronic ignition.
Note:
Dual voltage specifications(I. E. 100/120V, etc. )are inapplicable.
The shape of the AC plug socket can be changed upon request.
Frequency and coltage are changeable depending on orders.
Generator
| MODEL
| ZC1700
| ZC2700
| ZC4700
| ZC6700
| ZC2500
| ZC4500
| ZC6500
|
Frequency(Hz)
| 50
| 60
| 50
| 60
| 50
| 60
| 50
| 60
| 50
| 60
| 50
| 60
| 50
| 60
|
Rated
Power(W)
| 1500
| 1700
| 2000
| 2300
| 3500
| 4000
| 5000
| 6000
| 2000
| 2300
| 3500
| 4000
| 5000
| 6000
|
Voltage(V)
| 220
| 120/220
| 220
| 120/220
| 220
| 120/220
| 200(440/230)
| 240/120(420/240)
| 220
| 120/220
| 220
| 120/220
| 200(400/230)
| 240/120(420/240)
|
Rated Current(A)
| 5.5
| 11.7
| 9.1
| 19.2
| 15.9
| 33.3
| 22.7(7.2)
| 20.8/41.77(8.3)
| 9.1
| 19.2
| 15.9
| 33.3
| 22.7(7.2)
| 45.8/22.9(9.4)
|
Run Time(Hs.)
| 15
| 12
| 10
| 8.2
| 10
| 8.2
| 8
| 6.6
| 10
| 8.2
| 10
| 8.2
| 8
| 6.6
|
Start Model
|
| DC12V
|
| DC12V
|
Engine
| Mix Gass&Oil
| Gasoline
|
Fuel Tank(L)
| 12
| 12
| 22
| 22
| 12
| 22
| 22
|
Displacement
| 171cc
| 171cc
| 357cc
| 357cc
| 171cc
| 357cc
| 357cc
|
Noise level(at 7m )
| 64dBs
| 66dBs
| 66dBs
| 67dBs
| 71dBs
| 73dBs
| 73dBs
| 75dBs
| 65dBs
| 68dBs
| 71dBs
| 73dBs
| 73dBs
| 75dBs
|
Engine type
|
|
Package
| Dimensions(cm)
| 44×53×46
| 44×53×46
| 68×52×52
| 68×52×52
| 60×44×45
| 68×50×59
| 68×50×59
|
N/GW.(kg)
| 38.5/41.5
| 41.5/44.5
| 75/77
| 83/86
| 38/42
| 75/77
| 78/82
|
