Gas /Natural Gas/ Biomass Power Generator Set (WSFD)

Gas /Natural Gas/ Biomass Power Generator Set (WSFD)
Price: US $ 6880/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T,Paypal,Western Union
Gas/Natural Gas/Biogas/Biomass Generator
Conditions for Using of the Gas/Natural Gas/Biogas/Biomass Generator
1. Temperature of the straw gas used in this biomass generator set should not surpass 40 Celsius when it is 1m or nearer to the pressure regulating valve for air inflow.
2. The pressure that this biomass generator set can sustain ranges from 3kPa to 10 kPa and the fluctuated frequency of the pressure should not surpass 1kPa/min.
3. The granularity of the impurity should not surpass 5 μ M and its max. Content is 30mg/Nm3.
4. For the straw gas used in this biomass generator set, the volume content of H2 should not surpass 20% and the max. Content of H2S, NH3 and tar are 50mg/Nm3, 20mg/Nm3, and 50mg/Nm3.
5. The moisture content in straw gas should not surpass 40g/Nm3 and the heating value of the straw gas should not lower than 4MJ/Nm3.
For gas that cannot reach the conditions above, special allocation will be took for this biomass generator set after evaluation according to the specific composition, pressure, temperature, etc. Provided.

Technologies Used
This biomass generator set uses electrically fuel gas mixing technology, low-pressure air inflow technology, automatic control technology for burning and safe conveying system.

Technical information:
Type: WSFD
Engine Model: 30GF
Rated power: 30kw
Rated Voltage: 400/230V
Rated frequency: 50Hz
Power Factor: 0.8lagging
Rated Speed: 1500r/min
Generator Type:
Phase: AC 3-Phase, 4 wire
Voltage Steady State Regulation: ≤ ± 2%
Voltage Transient State Regulation: ≤ ± 10%
Heat Consumption: ≤ 11386 KJ/kw/h
Oil Consumption: ≤ 1.63 g/Kw/h
Total Displacement: 4.33L
Number of Pot: 4
Diameter of Pot: 105mm
Starting Mode: DC 24V electric motor
Cooling Mode: Water cooling
Lubricating Mode: Passive and flying lubricant
Excitation Mode: Brushless
Controlling System: Automatic alarm system
Guarantee Period: 1 year
Prod Model: WSFD
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Capacity: 30 Sets Per Month
Established in 2006, Golden Machinery Equipment Co., Limited is one professional manufacturer integrating R&D, manufacturing and trading, we are committed to coal process machine line, straw briquette machine line, food machine line, farming, agriculture equipments for years. We have 80 staff members and 16 technicians of research team. So we have more competitive strength, advanced processing technology and scientific management. And we are located in Zhengzhou city, Henan province, which is the business and economy center with easy transportation. Our international airport name is Zhengzhou Xinzheng International Airport.

We supply:

1, Wood and feed pellet machine: Pellet mill, pellet machine, feed pellet machine, fish feed machine, animal feed machine, fertilizer pellet machine and so on.

2, Crusher and grinder: Coal and charcoal crusher, straw crusher, fruit crusher, wood crusher, grain crusher and combined machine, wood chipper, wood shredder, multifunctional stainless steel crusher, grain grinder, coffee grinder, corn grinder and so on.

3, Woodworking machine: Wood peeling machine, wood chipper, wood crusher, wood grinder, wood shaving, and so on.

4. Construction machine: Brick making machine, concrete mixer, stone and cement crusher, conveyor, colour machine, automatic wall remending machine and so on.

5. Briquette machinery: Coal and charcoal briquette machine, sawdust briquette machine, biomass briquette machine, carbonization machine and so on.

6. Food fruit vegetable processing machinery: Harvester, washer, roaster, peeler, cutter machines, kitchen machine, juicer machine, dryer machine

7, Dryer and packing machine: Grain packing machine, snack packing machine, vacuum packing machine, automatic pillow packing machine, shream packing machine and so on.

8, Recycling machine: Plastic crusher, plastic granulator, metal crusher, cloth cutter, radiator separator machine and so on.

The notable quality and outstanding performance endow these products enjoying great popularity among our customers.

Should you have interest of items mentioned above? Kindly let us know by return mail. Meanwhile if you require the other merchandises made in China, pls feel free to contact me.

Looking forward to hearing from you soon.
