Re: S (in Model No. ) -- soundproof type generator
"Prime Power (PRP): Prime power is available for an unlimited number of annual hours in variable load application, in accordance with GB/T2820-97(eqvISO8528): A 10% overload capability is available for a period of 1hour within 12-hour period of operation.
Standby Power (ESP): The Standby Power is applicable for supplying emergency power for the duration of a utility power interruption. No overload, utility parallel or negotiated outage operation capability is available at this rating. "
I. Scope of supply
1. Brand new diesel engine.
2. Brand new AC alternator, Ratings: 230/400V, 3pH, 60Hz, 1800Rpm, 0.8PF, IP22, " H"classinsulation
3. Standard Radiator mounted on skid.
4. Auto control panel, manual and auto control panel, LCD display, indicated as PK-02 in specification
5. Circuit breaker.
6. High efficient shock absorb
7.24V lead acid battery and battery cables and battery rack
8. Dry type air filter, fuel filter, oil filter
9. Silencers with flexible connection pipe
10. All silent type genset will be with a base fuel tank for at least 8 hours running,
11. English operation/maintenance manuals/test report for engine, alternator and genset.
12. Standard tools kit.
|
Diesel Generator 60Hz, 3 phase, 4 wires, 0.8pf(lagging) |
|
Model |
Stanby Power |
Prime Power |
Engine |
Engga Alternator |
Diemensions |
Weight |
|
KW / KVA |
KW/KVA |
Manufacturer |
Model |
Model |
L * W * H (mm) |
(kg) |
|
PFO100-60TS |
88 |
110 |
80 |
100 |
OMNITEK |
OM6NG5-88G |
EG225L-88SN |
3000*1240*1760 |
1700 |
After over a decade´ S developing, Dalian Puyang Generating Set Co., Ltd. has become the leading generating set manufacture in Northern China. We have the largest scale of production and full product specifications and models. Puyang diesel generating set has past the test of China National Internal Combustion Set Quality Test Centre, we have also got the telecommunication facilities network import license of National Telecommunication Department and marine product certification of PRC, and we have been authorized by ISO9001 and WSSN2000 as well.
We have got long-term cooperation partners such as Cummins, Man, Volvo, Doosan, Mitsubishi, Shangchai, Weichai, Laidaong, Marathon, Engga, etc. With self-contained producing conditions, advanced testing equipments and abundant technologies, we can provide diesel generators from 8kw to 1800kw.
At present, we can supply standard diesel generator, automatic starting diesel generator, full automatic telemonitoring diesel generator, removable (mobile) power station, silent / soundproof diesel generator, weatherproof diesel generator, refrigerator car and marine product generating sets, etc. We have the only one full--function testing centre in Northern China, and we strictly follow the standard of GB/T2820 and ISO8528"AC generator set" to examine all functions of generating sets to guarantee 100% pass rate of our products.
