Foshan Generator Set Factory with Best Price and Good Service

Foshan Generator Set Factory with Best Price and Good Service
Price: US $ 1set
Trade Terms: FOB,CFR,CIF
Min Order: 1set
Pay Type: L/C,T/T


Factory Direct sales!
Model: 4BT.3.9-G2
Origin: Manufactured by Dongfeng  Engine Co., Ltd
Start Model: DC24V electric start
Steady Speed Droop:≤1%
4 cylinders ,in-line,4 stroke
 Technical Datasheet

Speed

1500r/min(50Hz)

1800r/min(60Hz)

Output Power

Engine Output

Engine Output

Standby Power

35kW

45kW

Prime Power

30kW

40kW



Generator set specifications
Governor ClassISO8528 G3
Potential Drop1%
Steady Voltage Regulation1%
Frequency DropSynchronous (0%)
Steady-state Frequency0.25%
R.R.I.Suppression BS EN 61000-6-4 / BS EN 61000-6-2
Fuel Consumption Rate ,g/kw.h(L/hr215 (5)
Starting Battery Capacity ,A/hr 60*2
Total Coolant Capacity ,L 24
Engine Data
Model 4BTA3.9-G2
Type in- line 4 Cylinder,4 Cycle
Displacement ,L 3.9
Compression Ration 16.5:1
Aspiration Turbo, Air / Air cooling
Fuel System AD type Fuel Pump,EFC Electronic Governor
Bore*Stroke(mm) 102*120
Rated Speed ,rpm 1500
Governor Type Electronic
Starting Voltage 24V ,Negative ground
Battery Charging System 24V 35A
Lubricant Capacity ,L 16.4
Coolant Capacity, L 24
Alternator Data
Protection Class IP21
Insulation Class Class H
Temperature Rise in Standard 125 °C(When Ambient Temp.is 40 °C)
Excitation Type Brushless & Self-excited
Waveform DistortionNo load<1.5% Non-Distorting balanced linear load<5%
Telephone Interference(TIF) <50
Telephone Interference(THF ) <2%


Electric AC synchronous brushless Leadtech alternator :
Our standard generator set match with electricity generator head LEADTECH/Stamford, also can match it by customer request.
Brushless self-exciting synchronous AC alternator. Three phase, 12 reconnect able leads
Stators are wound to 2/3 pitch.
Standard AVR controlled
Manufacture standards: GB755, BS 5000, VDE 0530, NEMA MG1-22, IEC34, CSA C22.2-100 and ASB59

 Control system:
Smartgen 6110 & 6120 control system also can use other brand according to customer requirement. Such as, HGM6310, HGM6320, DSE3110, DSE5110, DSE7110 and DSE7210 and etc.
Intelligent LCD display, automatic control, Chinese and English operation interface.
Function:high water temperature, low oil pressure, low speed and over load protection

ATS(Automatic Transfer switch)
It's widely used in hospital,airport,hotel,school and other emergency power supply equipments.
Once the main power failure, the control panel will received the signal to start the genset within 5 seconds, ATS will switch to the load wires to connect genset power supply,and the whole process takes less than 15 seconds. After the main power recovered 30 seconds, ATS automatically switch the load wires to connect main power supply,the genset will stop after running 180 seconds.

Optional accessories /spare parts:
Sound and water proof enclosure
Trailer/ Movable power station
Battery charger by main supply
jacket water heater
Oil heater
Diesel oil heater
Automatic transfer switches (ATS) & paralleling system
Extra fuel tank
Fuel-water separator

Guarantee and after sale service
Warranty:One Year or 1000 running hours, whichever comes first. with more than one hundred maintenance shops all over worldwide, it is very easy to find the spare parts and get technology support.
24hours technical support by E-mail.
testing :
All generator sets are gone through rigorous testing before being released to the market place, include 50%load,75% load,100% load,110%   load and all protection fuctions (over speed, high water temperature, low oil pressure, battery change fail, emergency stop) .

Warmly welcome to our factory for visit:
1.From Guangzhou Baiyun International airport to Oripo.

a.It takes about 1 hour by car/taxi,it is about 58 kilometer.

b.Or take the subway from JiChangNan station to HanXiChangLong Station(you need to transfer at the

TiYuXiLu station to PanYu direction), then take a taxi to Oripo, it will take about 1.5 hour.

2.From Canton fair complex to Oripo.

a. It takes about 30 minutes by car / taxi, it is about 32 kilometer.

b. Take the subway from XinGangDong Station / PaZhou station to HanXiChangLong Station, then take a

taxi to Oripo, It will take about 1 hour.




Standard Parts
Brand new  electric governor diesel engine and brushless self exciting 100% copper alternator.
Daily base fuel tank with 8 hours capacity
Intelligent LED display control panel;
Speed governor & CHNT brand AMF(MCCB)
Electric start and 24v charger;
Standard air filter, oil filter, fuel filter;Cooling water tank;
High-efficient silencer
Exhaust elbow & Storage battery
Steel base-frame against vibration;
Soft pipe for fuel and handle for lube going-out;
Operation& Maintenance manual.
Tool kit.                                                                                                                                                                                                                     X
Optional parts1, original filters.(First time, each 150 hours need to exchange it, after that 350 hours of each time)
2, Jacket water heater
3, Diesel oil heater
4, Lubricate oil heater
5, Battery charg                                                                                                                                                                                                                             6.Optional ATS
 Prime Power : Prime power is available for an unlimited number of annual hours in variable load application, in accordance with GB/T2820-97(eqvISO8528); A 10% overload capability is available for a period of 1 hour within a 12-hour period of operation.
Standby Power : The standby power rating is applicable for supplying emergency power for the duration of a utility power interruption. No overload allowed, utility parallel or negotiated outage operation capability is available at this rating.
Delivery Lead time: on about 18days
Price based on FOB Foshan
Payment terms: By T/T 30% in advance and the balance 70% shall be paid before shipment.
 Nogotiable
Validity
One month after this quotaton offered.
Package:
 1 set by poly film/plywood or as customer request
Warratny:
 1year or 1000 working hours, whichever comes first. After expiration,Provides cost maintenance.











Prod Model: OCL50
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type: Self-Starting Diesel Generator
Installation Method: Portable
Stroke: Four Stroke
Cooling Method: Water Cooling
Output Type: AC Three Phase
Oripo Established in 1998, Oripo Power Engineering Co., Ltd is professional leading manufacturer, suppliers, exporter and authorized dealers of diesel gensets. With over 20, 000 square meters and a staff nearly 200, the headqauter is loacted in Foshan city, adjacent to Guangzhou which is the trade center of Guandong province. We offering power genset, industrial genset, silent genset, weather proof genset, Cummins genset, Perkins genset, Yuchai genset, Shanghai Dongfeng genset, Deutz genset, Weichai electric genset, China domestic genset, silent diesel generator, portable power generator, trailer diesel generator and electric power generator.

Currently, Oripo cooperated with multinational companies formed a strategic partnership. Import CUMMINS, PERKINS series generator sets, and purchase engine from with Cummins, SDEC, Yuchai, LOVOL, Deutz, alternater with STAMFORD, MARATHON, LEADTECH and other international or domestic famous brand. Establish a long-term friendly cooperation relations with the branded engine and alternator company, authorized to be the OEM partner, In 2009, Oripoe authorized by Cummins, Shanghai Dongfeng and Yuchai to provide OEM service. As professional qualified manufacturer provide OEM genset, spare parts, after sale service, in order to better serve customers and laid a solid foundation.

During the last ten odd years, Oripo has been dedicated to pursuing professional production, thus prevailing in the market with its superior quality, cutting-edge technology and tailor-made services. Moreover, with an endeavor to expand our business operations, we adhere to ethical business practices, transparent business dealings and work to attain the confidence and trust of our clients.
