Quick Details
Place of Origin: Jiangsu, China (Mainland)
Brand Name: FARADAY
Model Number: FD1F
Output Type: AC Three Phase
Speed: 1500/1800
Frequency: 50/60
Rated Power: 22.5KW
Rated Voltage: 380v
Payment terms: T/T, L/C
Output type: AC three phase
Power factor: 0.8
Wire widing: 100%copper wire
Speed: 1500/1800
Warranty: 24 months
Class of Insulation: H/H
Original: WUXI China
Protection Grade: IP23
Rated Voltage: 190~690V
Packaging & Delivery
Packaging Details: PLYWOOD CASE
Delivery Detail: 15 DAYS
Specifications
Brand: FARADAY
Frequency: 50/60HZ
Speed: 1500/1800 RPM
Rated Voltage: 380~480V
Output Type: Single phase /threeFARADAY FD1 Series Alternator data for your reference:
Alternator Specification:
3 PH, 50HZ@1500RPM, 400/230V(Also can be made according to customers' special requirements)
|
Model |
Output |
Voltage (V) |
Power Factor |
Phase No.
|
Speed (rpm) |
Freq. (Hz) |
Pole No. |
|
KVA |
KW |
|
FD1A |
8.1 |
6.5 |
380-415V |
0. 8 |
3
|
1500 /1800 |
50 /60 |
4 |
|
FD1B |
11 |
8.8 |
|
FD1C |
13.5 |
10.8 |
|
FD1D |
16 |
12.8 |
|
FD1E |
22.5 |
18 |
|
FD1F |
27.5 |
22
|
|
Alternator Model |
FD1K |
|
Power |
40kva / 32 kw |
|
Exciter type |
Brush less , Self excitation system |
|
Power factor |
0.8 |
|
Voltage adjust range |
≥3% |
|
Voltage regulation NL-FL |
≤±0.3% |
|
Insulation Grade |
H |
|
Protection Grade |
IP2 3
|
With world-leading technology and advanced management experience in operation, Wuxi Faraday Alternators Ltd is cooperating with American Basler Electric Company in excited system, being professionally engaged in the production and sales of "FARADAY" alternators, power ranged from 6.5kw to 2000kw.
BUSINESS PRINCIPLE:Carving out with integrity to pursue employee satisfaction, customer satisfaction as well as society satisfaction for life
DEVELOPMENT STRATEGY:Guaranteeing quality with criterion, building brand by quality, developing with brand
MANAGEMENT STAFF:Our senior management staffs are all professional talents who have ever worked in multinational company for so many years in alternators' production and sales, with extensive experience of marketing and service, production, material supplied chain management and quality control system.
PRODUCT FEATURE:Cooperating with American Basler Electric Co., innovating under the world-leading technology combined with the feedback from actual practice:Overcoming the AVR shortage of the usual domestic alternator, reasonable design, compact overall dimension, light weight, class "H" of all stators and rotors' insulation, stable and reliable even during bad working condition, etc., with patent registered already.
CUSTOMER SUPPORT:We have an excellent service and industry solution team who have been engaged in alternator field for over ten years, we can assure customers that complaint or help will get swift response, within 24 hours to be on the spot in Jiangsu province and 48 hours in nationwide is available if necessary.
CORE COMPETENCE:Topping employee, advanced ideas, leading technology, reliable quality and timely service are our core competence.
