| Price: | US $ 17250-18620/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T |
| 1.Genset Technical Data: | |||||||||
| Gensets model | GDC250*S | ||||||||
| Prime power | 200KW/250kVA | ||||||||
| Standby power | 220KW/275KVA | ||||||||
| Rated speed | 1500RPM | ||||||||
| Output frequency | 50Hz | ||||||||
| Power Factor | 0.8 | ||||||||
| Phase | 3 | ||||||||
| Rated voltage | 400/230V | ||||||||
| Dimensions(mm) (L×W×H) | 2400*860*1380 | ||||||||
| Genset Weight(kg) | 1440 | ||||||||
| Prime Power: | |||||||||
This rating is for the supply of continuous electrical power (at variable load). There is no limit on the annual hours of operation and 10% overload power can be supplied for 1 hour in 12. | |||||||||
Standby power: | |||||||||
This rating is for the supply of continuous electrical power (at variable load) in the event of a utility power failure. No overload is permitted. | |||||||||
| Rated voltage : | |||||||||
| Available with customer requirements. | |||||||||
| 2. Specification of diesel engine: | |||||||||
| Engine brand | Cummins | ||||||||
| Engine model | 6LTAA8.9-G3 | ||||||||
| Number of Cylinders | 6 | ||||||||
| Cylinder arrangement | 6 Vertical in-line | ||||||||
| Cycle | Four stroke | ||||||||
| Aspiration | Turbo,Water/Air Cooling | ||||||||
| Fuel System | PB type fuel pump | ||||||||
| Bore×Stroke (mm×mm) | 114x 135 | ||||||||
| Displacement (Liter) | 8.3 | ||||||||
| Compression Ratio | 17.0:1 | ||||||||
| Speed Governor | Electrical | ||||||||
| Cooling System | Forced Water Cooling Cycle | ||||||||
| Speed Stability (%) | ≤1% | ||||||||
| Total lubrication system capacity (L) | 27.6 | ||||||||
| Fuel Consumption at 100% Load (g/kwh) | 209 | ||||||||
| Starting Method | DC24V Electrical starting | ||||||||
| 3. Specification of alternator | |||||||||
| Alternator brand | Stamford | ||||||||
| Alternator model | UCI274G | ||||||||
| Number of Phase | 3 | ||||||||
| Connecting Type | 3 Phase and 4 Wires | ||||||||
| Number of Bearing | 1 | ||||||||
| Protection Grade | IP23 | ||||||||
| Altitude | ≤1000m | ||||||||
| Exciter Type | Brushless ,Self-exciting | ||||||||
| Insulation Class | H | ||||||||
| Telephone Influence Factor (TIF) | ≤50 | ||||||||
| THF | ≤2% | ||||||||
| Voltage Regulation, Steady State | ≤±1% | ||||||||
| Transient State Voltage | ≤-15%~+20% | ||||||||
| Prod Model: | GDC250*S |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Wire: | 100% Pure Copper Wire |
| Alternator: | Stamford, Marathon, Engga |
| Engine: | Cummins, Mtu, Deutz Is Optional |
| Controller: | Dse, Smartgen Is Optional |
| Function: | ATS/Amf, Open/Soudproof Is Optional |
| Type: | Basic Diesel Generator |
| Installation Method: | Fixed |
| Stroke: | Four Stroke |
| Cooling Method: | Wind Cooling |
| Output Type: | AC Three Phase |
