PG Modified Sine Wave Inverter
PG modified sine wave inverter is a combination of an inverter and a charge. It offers a smart, convenient and economic way to get AC power supply from DC source for most electrical equipment. When the AC input is available, it will switch to AC power supply and starts charging on the batteries.
Features
1. With high frequency design and modified sine wave output, the modified sine wave inverter offers high efficiency.
2. Automatic switch between mains power and battery power supply.
3. Rack tower design, compact size for convenient use and storage
4. Off mode charging function is available
5. Selectable switch for wider input voltage.
6. Full automatic and silent operation
7. Built-in 10AMP super charger for up to 100Ah battery
8. Two-step intelligent charging control system is available to control recharging time.
9. The modified sine wave inverter comes with informative LED indicator and alarming functions.
10. Full protections against various abnormal situations
11. Different AC outlet configurations are available: NEMA, Schuko, French, India, and BS1363
12. This is a small scale and cost effective modified pure sine wave inverter for home appliances and office equipment.
Technical Specifications
Model |
PG 500 |
PG 1000 |
PG 2000 |
Capacity |
VA/W |
500VA / 300W |
1000VA / 600W |
2000VA / 1200W |
Input |
Phase |
Single |
Voltage |
110 / 120VAC or 220 / 230 / 240VAC |
Voltage Range |
90 - 145VAC or 170-280VAC ( Narrow Range ) |
50-145VAC / 90-280VAC (Wide Range) |
Output |
Phase |
Single |
Voltage |
120VAC or 230VAC |
Voltage Regulation(Batt. Mode) |
+10% ~ 18% |
Frequency |
50Hz or 60Hz |
Frequency Regulation (Batt. Mode) |
+/- 0.1 Hz |
Output Waveform (Batt. Mode) |
Modified Sine Wave |
Power factor |
P.F. |
0.6 |
Battery |
Charger Current |
8 Amp + / - 1Amp |
6 Amp + / - 1Amp |
10 Amp + / - 1Amp |
Floating Voltage |
13.7V + / - 0.2V |
27.4V + / - 0.4V |
27.4V + / - 0.4V |
Overcharge Protection |
15V +/- 0.3V charger stops and fault |
15V +/- 0.6V charger stops and fault |
30V +/- 0.6V charger stops and fault |
Transfer time |
Typical |
8ms |
Efficiency |
AC to AC |
>95% |
DC to AC |
>80% |
Indicator |
AC Mode |
Solid Green LED |
Battery Mode |
Solid Yellow LED |
Battery Charging Mode |
Green LED flashes at 2 seconds intervals |
Overload |
Red LED flashes at 0.5 second intervals |
Fault |
Solid Red LED |
Audible alarm |
Low Battery at Battery Mode |
Beeps at 2 seconds intervals |
Overload |
Sounding at 0.5 second intervals |
Fault |
Beeps Continuously |
Protection |
Full Protection |
Deep Discharge, Overcharge, and Overload protection |
Physical |
Dimension (L×W×H) mm |
224 ×260 × 80 |
Net Weight (kgs) |
1.7 |
1.9 |
2.5 |
Environment |
Operating Environment |
0~40 Degrees Centigrade, 0~90% relative humidity (non-condensing) |
Noise Level |
Less than 50dB |
