Experienced 500kw Biogas Generator Set (500GJZ1-PWT-ESM3)
| Price: |
US $ 2560-340438set/sets |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1set/sets |
| Pay Type: |
L/C,T/T,D/P,Paypal,Money Gram |
Experienced 500kw Biogas Generator Set (500GJZ1-PWT-ESM3)
AVESPEED BIOGAS GENSETS SPECIFICATIONS
All data according to full load subject to technical development and modification
Biogas should be purified before burning in engine
Biogas temperature ≤40centigrade
Biogas pressure 3~10kPa; Fluctuate rate of pressure ≤1kPa/min
CH4≥40%; Fluctuate rate of CH4 ≤2%min
H2S≤200mg/Nm3,
NH3 ≤20mg/Nm3,
Granule≤5μm,
Granule≤30mg/Nm3;
Moisture ≤40g/Nm3
You must also like these gas generator sets:
|
Genset model |
500GJZ1-PwT-ESM3 |
|
Engine model |
T12V190ZL-2 |
|
Alternator model |
1FC6 455-6LA42 |
|
(kW) Rated Power |
500 |
|
(A)Rated current |
902 |
|
(V)Rated voltage |
400 |
|
,COSΦ Rated power factor |
0.8()0.8 (lagging) |
|
(Hz)Frequency |
50 |
(MJ/kWh)
Fuel consumption |
10.3 |
|
(g/kWh) Lube oil consumption |
≤1.0 |
|
Switch on method |
24V24VDC |
|
Starting Mode |
Automatic |
|
Voltage control method |
Automatic |
|
Speed regulation method |
Electronic governor |
|
Excitation way |
Brushless |
|
Wiring method |
Three-phase,four-wire system or Three-phase, three-wire system |
|
Cooling method |
Closed type |
|
Connection type |
Flexible couping connection |
|
Dimension, L×W×H(mm) |
5433×1970×2700 |
|
(kg)Weight |
10750 |
|
(h)Overhaul period |
30000 |
|
Model of engine |
T12V190ZL-2 |
|
Configuration and type |
four stork, direct injection fuel system
4, |
|
Cylinder arrangement |
V60°
V type 60°included angle |
|
No.of cylinder |
12 |
|
(L) Total displacement, L |
71.45 |
|
Rated speed(r/min) |
1000 |
|
Idle speed(r/min) |
600 |
|
Rated power(kW) |
550 |
|
Fuel consumption(MJ/kWh) |
9.5 |
|
Lube oil consumption(g/kWh) |
≤0.8 |
|
Jacket water temp( centigrade ) |
≤85 |
|
( centigrade ) Lube oil temp( centigrade ) |
≤90 |
|
Lube oil pressure in oil main line(kPa) |
400~800 |
|
(%) Stable speed drop |
0~5
0~5 adjustable |
|
Lubricating system |
Pressure and splash lubrication |
|
Ignition method |
Spark plug ignition |
|
Starting method |
24V24VDC motor |
|
Direction of rotation |
Clock-Wise (viewed from the front)
() |
|
Speed Regulation |
Electronic Governor |
|
Cooling system |
Forced circulation water cooling |
|
Output way |
flywheel output |
| Prod Model: |
500GJZ1-PWT-ESM3 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Rated Power: |
500kw |
| (a)Rated Current: |
902 |
| V) Rated Voltage: |
400 |
| (Hz)Frequency: |
50 |
| Speed Regulation Method: |
Electronic Governor |
| Wiring Method: |
Three-Phase,Four-Wire System or Three-Phase, Three |
| Dimension, L*W*H(Mm): |
5433*1970*2700 |
| Overhaul Period: |
30000h |
| Engine Speed (Rpm): |
1000 |
| Gas Source: |
Biogas |
Beijing Avespeed Commercial & Trading Co., Limited is the leading manufacturer and supplier of diesel engines for marine propulsion, marine Gen-sets, stationery Gen-sets and power plant applications in China. AVESPEED manufactures diesel engines with unit output from 150KW to 4500KW, which can be used as propulsion of merchant vessels and special vessels from 1000 to 30000 tons DWT. AVESPEED manufactures marine auxiliary diesel generators with unit output from 150KW to 4500KW and stationery HFO generators with unit output from 500KW to 8000KW.
AVESPEED designs and builds turn-key power plant with an output up to 100MW as base load power plant, peaking power plant or industrial self-captive power plant in cement, textile, mining or oil and gas industries etc. The power fuel can be diesel oil, bio-diesel, heavy fuel oil (HFO) or bi-fuel. AVESPEED has been set up more than 200 heavy fuel oil (HFO) power plant projects in the world in recent years, especially in Nigeria, we have set up more than 60 HFO power plant projects there.
All of our marine diesel engines have achieved type approvals and work test approvals of, CCS, China Ships Inspection Bureau, and China Fishing Ships Inspection Bureau. Many products are rated as "National Grade New Products" and "Industry Brand Products" and awarded with "National Prize for Progress in Science and Technology", Now AVESPEED diesel engines are widely used for deep sea fishery, inshore fishing ships, ocean shipping, inland water navigation, passenger cargo ship transport, harbor tug, engineering ships, enforcement ships, naval auxiliaries etc.
New energy products developed in recent years including natural gas generator sets, biomass generator sets, tyre oil/vegetable generator sets and dual-fuel generator sets with unit output from 50KW to 1000KW.
AVESPEED also involves in the development and manufacture of the crystal silicon (mono and poly) solar panel/module, photovoltaic system, and other photovoltaic products. We supply solar panels ranging from 45W to 290W. AVESPEED's on-grid and off-grid inverters are the sole in China certified by TUV. The PV inverters range from 1KW to 1000KW.
Our products and manufacturing processes fully comply with product safety requirements, including TUV/IEC61215 & 61730, CSA/UL1703, MCS, CE and UKAS. Additionally, we have implemented best practices to protect the environment and conserve energy.
So far, our customers spread dozens of countries and regions in Europe, Middle East, Africa, South America, Southeast Asia and West Asia. AVESPEED is willing to cooperate with relevant famous enterprises and far-sighted, strong-willed and talented people at home and abroad by supplying our high-quality products and excellent service.
