Home Generator Products Ete Power Silent Type 20kw Diesel Generator Price

Ete Power Silent Type 20kw Diesel Generator Price

Ete Power Silent Type 20kw Diesel Generator Price
Price: Negotiable/Piece
Trade Terms: FOB
Min Order: 1/Piece
Pay Type: L/C,T/T
Silent diesel generators


Detailed Selling Lead Description

Trailer gen-set from 20kW to 1000kW can be mobile with the brake, and the engine u can choice( Cummins, Perkins, Volvo and Deutz engine) and global-famous alternator Stamford, Marathon and Leroy Somer,
Installed with spring damping equipment, and two wheels and four wheels structure

Standard configuration supply scope:

(1)Diesel engine with all accessories, 3 filter, electrical systems.
(2)Alternator.
(3)Steel structure.
(4)Fan and water cooling system.
(5)Flange connector.
(6)12V/24vstarting motor and charge engine.
(7)Air cleaner, fuel cleaner, oil cleaner.
(8)On-board control panel.
(9)MCCB air conservation switch.
(10)12V/24V starting accumulator and bettery line.
(11)Set shock absorber.

Control system:

*Optional brand: Smartgen, Deep Sea, Comap. etc.
*Installation: Airborne type, independently controlled type.
*Manual/automatic control unit start/stop
*The instrumentations and the select switch
*Unite operating parameter display: LCD/graphics/meters
*Auto start switching when the main power falls (optional)
*Automatic parallel connection control module of multi-generator sets(optional)
*The functions of remote control interface, remote control, remote test and remote sigal(optional)
*MCCB air switch protects overload short-circuit(optional)


Optional Accessories
1, Preheating Start System
2, Diesel Engine Thermal Protection System
3, Jacket Heater
4, Speeding, High Temperature, High Oil Temperature, Low Pressure Alarm System
5, Breaker
6, Antifreeze Liquid
7, Ground Wire
8, Water Temperature Safety Device
9, Machine Oil

Service Conditions
-- Ambient Temperature: -25° C~40° C
-- Altitude: Not exceed 1000 Meter
-- Rated Voltage: 230/380V or any voltage between 220-440V
-- Rated Frequency: 50Hz/60Hz
-- Insulation Class: B/F/H
-- Working Duty: S1(Continuous)
-- Humidity: Lower than 95%

Excellent access for maintenance

1) Two doors on each side
2) Radiator fill access plate
3) Lube oil and cooling water drains piped to exterior of the enclosure
4) Operate easily, and can be used outside while no room has to be built for it, Large bottom fuel tank ensures long working time

Warranty

The goods are under warranty against defects in material and workmanship for a period of 12 months or 1000 hours, whichever come first from the date of delivery to the end user except the damageable spare parts of genset caused by incorrect man-made operation, and that the aforementioned warranty for the same taken is back up by the engine and alternator suppliers.


Products and package: \
Volvo Generator Set   Engine
Brand                                 WANDI Brand                                 VOLVO PETNA
Model   WDV120 Model   TAD731GE
Prime power KVA/KW 150/120 Rated power(net) KVA/KW 165/132
Standby power KVA/KW 165/132 No. of cylinder   6
Frequency Hz 50 Cycle type   4-cycle
Rated voltage V 400/230 Cylinder arrangement   Vertical in line
Rated current A 216 Aspiration type   Turbocharged
Power factor COS Φ 0.8(lag) Combustion system   water cooled
Fuel tank capacity L 340 Speed mode   Mechanical
Sound pressure level LP dB(A)1m 85 Bore mm 108
Alternator Stroke mm 130
Brand FARADAY Compression ratio   18.0:1
Model FD3D Displacement L 4.67
Connecting type 3 phase and 4 wires Engine oil capacity L 20
Excitation type brushless, self excited Total coolant capacity L 23.8
Steady voltage regulation ≤ 1% Exhaust smoke   1bosch
Transient voltage regulation ≤ ±25% Lubrication consumption L/H 0.1
Frequency recovery time ≤ 3s Fuel consumption g/kw@h 215
Protection IP23 Cooling max water temperature   ºC 104
Insulation Class H Governor type   Electronic
Overload capacity ≤ 10% Start mode   Electronic
    Emission standards   Europe stageII
Dimension/weight
Open type Soundproof canopy type
Dimension (L*W*H) mm 2466*866*1437 Dimension (L*W*H) mm 3000*1240*1760
                  Net weight                 kg 1450                   Net weight                 kg 2270
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Place Of Origin: Jiangsu, China(Mainland)
Brand: Wandi
Modle Type: Silent Type
Frequency: 50Hz
Advantage: Fuel Efficiency, Silent Type
Rated Voltage: 400/230V
Warranty Period: 1 Year or 1000 Hours Running Working Hours
Option: Silent Canopy, ATS, Water & Oil Heater
Optional Parts: Parallel System, Air Breaker, Basic Fuel Tank..
Engine Standard: ISO9001, GB/T2820-97, ISO8528
Cooling Method: Water Cooling
Stroke: Four Stroke
Installation Method: Fixed
Type: Self-Starting Diesel Generator
Output Type: AC Three Phase
Wuxi Wan Di Power Engineering Group (formerly Wuxi Power Machine Factory) is a state-owned company mainly specializing in developing and manufacturing 6 cylinders, 12 cylinders series diesel engines, diesel generator sets and turbo-chargers etc. It was founded in 1946, one of the first manufacturers of genset in China, which has a good reputation in China till now

Our company named Wuxi Huayou Power Equipment Co., Ltd, a subsidiary corporation of WanDi Group, specializing in manufacturing and exporting various types diesel generator sets. It is one of the pilot enterprises assigned to invent and manufacture national military power supply, has a history of 40 years to supply military power. With an annual output up to 300, 000 KW, it is one of the most important Chinese diesel generator sets suppliers.

The products of our company mainly adopt diesel engines originally imported from Sweden such as Volvo; Joint venture engines that are American or British such as CUMMINS, PERKINS; Domestic engines Weichai or Wandi brand made by our own branch company to match British Stamford, Engga, Faraday alternators. We are OEM manufacturer of these above brands. All these different kinds of genset can be assembled to auto-start, low-noise or moveable sets according to customer' S require. They are widely applied in marine field, key projects, communication hubs, high-rise buildings and infrastructure construction projects.

For many years, we have provided large quantities of diesel generator sets to military equipments; Also provided reserve power supply to national foreign aid projects many times. We have already got great achievements in Southeast Asia, North America, Europe and many African countries such as Vietnam, Thailand, Singapore, Sudan, Egypt, Turkey, America, etc. Because of the Hi-technic, reliable quality nice contour, efficient service net all over the world. Our products are highly salable in both domestic and overseas markets.

Wan Di Series Diesel Generator Sets are enjoying a leading position in the same field nowadays. The generator sets of different types can certainly meet customers' Demands at different levels.
