1) Generator
A) Type: Brushless
B) Rate AC output: 0. 65kva/50Hz 0. 85kva/60Hz
C) Max. AC output: 0. 80kva/50Hz 0. 95kva/60Hz
D) Frequency: 50/60Hz
E) Voltage: 220/110V
F) Voltage regulator: Capacitor
2) Engine type:
A) Air-cooled, 2-stroke, single-cylinder
B) Model: 1E45F
C) Bore x stroke (mm): 45 x 42
D) Displacement (ml): 63. 6
E) Compression ratio: 7. 2: 1
F) Rate power: 1. 1kva/3000rpm, 1. 2kva/3600rpm
G) Max. Power: 1. 5kva/3000rpm
H) Max. Torque: 4. 58N. M/3000rpm
I) Ignition system: Capacitor discharge ignition (CDI)
J) Air cleaner: Foam filter element
K) Recommended fuel: Unleaded gasoline
L) Fuel tank capacity: 4. 2L
M) Fuel consumption: <420g/kva-hour
N) Engine oil capacity: Gasoline and oil mixing ratio 50: 1
O) Start mode: Recoil and hand-operated
3) Set
A) Cont. Working time (h): 5-6
B) Noise level (7m) dB (A): 65
4) Standard: AC socket / AC circuit breaker / engine switch / indicator light
5) Option: Battery / AC voltmeter / oil alert / DC socket (12V/8A) / DC
Circuit breaker / handle / idler
Packing:
Carton dimensions (L x W x H): 380 x 325 x 325mm
N. W.: 20kg
Conveyance:
Qty/20' FCL: 756 sets
