Soundproof generator set
General specifications of soundproof canopy:
Modular design
Anti-corrosion powder coated
Insulated with acoustic foam lining
Central lifting ring, exhaust pipe can be removed which is easy for transportation
Lockable doors with key
Protective mesh for rotating parts
Exterior emergency stop push button
Thermally insulated engine exhaust system
Panel observing window
Access to radiator filling or cap
20', 30' or 40' container canopy is optional
Color is optional
Fuel gauge or lube drain valve is optional
Normal or super soundproof canopy is optional
Base frame fuel tank or profile fuel tank is optional
The muffler's fixed position depend on the output power of gen-set
Silent generator set canopy:
* With special treated steel sheet
* StaiVess steel locks
* Control panel viewing window for monitoring the status of the generator set
* Good ventilation system and anti-heat radiation struction
* Effective anti-vibration devices to ensure the geneartor set run steadily
* Super silent materials inside to ensure the noise lower than 68 dB 7 meters away
* Emergency stop button mounted outside
* Side lockable door easy for maintenance and installation
* Lube oil and cooling water drains piped to exterior of the canopy
* Fuel tank built-in with level gauge
1. Rated voltage: 400V/230V, 380V/220V, 240V/120V, 220V/110V
2. Line way: 3 phases & 4 lines
3. Frequency: 50Hz/60Hz
4. Power factor: 0.8 (lagging)
5. Frequency down (%): ≤ 0.5
6. Steady voltage windage (%): ≤ ± 1
7. Instantanous frequency windage (%): (rated power ) +10~ -7
8. Frequency recovering time (s): ≤ 3
9. Instantanous voltage windage (%): +20~ -15
10. Voltage recovering time (S): ≤ 4
11. Wave form distortion (%): ≤ 5
