Rated frequency [Hz] 50 60
Rated voltage [V] 230 120/240
Rated current [A] 19.57 40/20
Rated output power [KVA] 4.5 4.8
Max output power [KVA] 5.0 5.5
Rated rotation speed [rpm] 3000 3600
DC output 12V8.3A
Power factor [cos] 1
Phase number Single phase
Noise level [dB(A)@7m] 70-74
Overall dimension (LxWxH) [mm ] 950x565x770
Dry weight [kg] 100 (220)
Structure type Silent type
Excitation mode Self-excitation brushless
Engine model SH186FAE
Engine type Single cylinder, 4-stroke, air-cooled, direct injection, diesel engine
Displacemen [ml (cu. In)] 418 (25.51)
Compression ratio 19: 01
Rated power [KW (Hp)/rpm] 6.7 (9.00)/3600
Starting system Electric starter
Rotation dircetion (View from flywheel) Clockwise
Fuel 0# (summer) or -10# (winter) light diesel oil
Lube SAE10W30 (above CC grade)
Low oil pressure alert system With
Battery With 12V-32Ah
Zhejiang Zeteng Machinery Co., Ltd. is a professional mechanical and electrical equipment enterprise located in Taizhou China belongs to SANYOU HOLDING GROUP Co., Ltd. As a reliable supplier in Power equipment industry, we have been exporting a variety of standard and custom designed gasoline engine, gasoline generator, and gasoline waterpump, compactor, diesel engine, diesel generator, diesel waterpump to worldwide market with extensive experience. We have abundant capital and handle our own product development, production and after- sales service.
SMD means super max design and has good reputation for its persistent guideline regarding credit and quality as the uppermost and offering customers the best suitable products and well-pleasing service with business in more than 20 countries such as Europe, America, Southeast, Middle East and Africa, etc. It operates an advanced production line with whole set of inspection and testing equipment and a yearly capacity of 150, 000 sets of machines. And we use a combination of traditional skills and new technology to maintain consistent quality all across the production range.
Our company has gain EPA, CE, GS certification for products and ISO9001 for company management. We always follow the principle of "Quality is the life, and customer is first. " SMD people sincerely hope to cooperate with all friends all over the world hand in hand to create a common glorious tomorrow.
