Diesel Welding Generator
| Price: |
US $ 625/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T |
Diesel welding generator
The smooth arc is available for any welding
With double purpose is adapt to outdoor using
15L
| Model | RPD5500EW |
| Generator | Rated frequency(Hz) | 50 | 60 |
| Rated output(kw) | 2.8 | 3.0 |
| Rated voltage(V) | 120, 220, 230, 240, 110/220, 120/240 |
| DC Output | 12V/8.3A |
| Phase number | Single |
| Power factor(cosΦ ) | 1 |
| Welding voltage at zero load(DC)(V) | 60-65 |
| Rated welding current DC (A) | 160 |
| Welding voltage(DC)(V) | 26 |
| Welding load continuous ratio | 60% |
| Welding current adjustment range(A) | 50-180 |
| Electrode(mm) | 1.6-4.0 |
| Excitation mode | Self-excitation and constant voltage |
| Engine | Engine model | RP186FA |
| Displacement(ml) | 418 |
| Bore x stroke(mm) | 86*72 |
| Rated speed(r/min) | 3000 | 3600 |
| Fuel consumption(g/kmh) | 360 |
| Fuel tank capacity | 15 |
| Continuous running time(hr) | 6.5 |
| Starting system | Recoil or electric start |
| Noise level at rated load Dba/7m | 75 |
| Unit | Net weight(kg)/(lbs) | 180/396.8 |
| Dimension(mm)/(inch) | 720x485x600 |
| 28.3x19.1x23.6 |
| Packing(mm)/(inch) | 740x505 x620 |
| 29.1x19.9x24.4 |
| Container Qty(20FT/40FT/40HQ) | 102/213/284 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Stroke: |
Four Stroke |
| Type: |
Basic Diesel Generator |
| Cooling Method: |
Air Cooled |
| Installation Method: |
Portable |
| Output Type: |
AC Three Phase |
Robust Power are a leading manufacture of generator and mobile
Light tower in China, We have achieved 16 proven patent of light tower, more than other Chinese supplier. Not just a trade company, and can research, the customers-based products.
In 2007, we won a tender of 300units light towers for peacekeeping forces of United Nation. At right now, we are two countries' United Nation project supplier.
Robust Power, is located in national grade industrial zone with beautiful scenery and convenient traffic extending in all directions of Fuzhou city, China. The predecessor of Robust was Fuzhou Rongli M & E Co., Ltd. which established in October 1990, is known as professional manufacturer of generator parts & control modules. Through two years of development, Robust Power has quickly formed an integrated chain from research and devolpment, production, sales, maintenance to customer service.
Diesel gensets of Robust Power System were explored according to the demand of the customers and the developing need of the society. It has passed the strict technical demonstration. It is the cooperation outcome of famous engine manufacturer CUMMINS, LOVOL, DEUTZ, England PERKINS, Japan KUBOTA, ISUZU, and Chinese famous engine manufacturer, together with the world famous generator LEROY SOMER, STAMFORD. It uses the latest intelligent control technical, and pushes out the optimal combination of quality, performance, value series diesel gensets. No matter for the prime power or the stand-by power, it all can provide a whole series diesel gensets and full automatic panel, full ATS, lower noise gensets and work-room noise-annuated project, trailer mobile power station type etc. These products are designed and configured into a whole, as a result, you can be at home with them.
On the basis of steady development of general mobile illumination products, after years of great efforts, Robust Power has developed several large-scale new product group of light tower including Janpan KUBOTA, ISUZU series, CUMMINS series, England PERKINS series & other Chinese brand series with output ranges from 4.5kVA to 30kVA, which is capable of meeting customers' requirements at different fields. We make our efforts to provide customers worldwide with the most economic, stable and practical mobile illumination equipments. In 2008, we won a tender of 300units light towers for peacekeeping forces of United Nation and we have supplied these light towers to UN till today.
Following the corporate culture "Trustworthy and Practical", Robust Power strive to be a first-class manufacturer in the line of mechanical and electrical products. With 15, 000m2 factory premises, we owns a number of production lines for mould fabrication, press shaping, welding & plastic spraying, assembly and testing. Now, Robust Power is staffed with 100 employees and 10% of them are engineers and technicians. Abiding by the principle "Quality First", Robust Power has established perfect and effective internal quality control regulations with complete measuring and testing equipments. Robust Power had attained ISO9001: 2000 certificate and got CE certificate for all of our products.
Although our gensets and mobile light towers takes an important part in the world's market with its high performance and incomparable price, we will still exert ourselves in developing better products for the whole world.
