Frequency: 50HZ
Generator output: 2.5Kw
Rated AC voltage: 220V
Power factor: 1
DC output: 12V 8.3A
Phase: Single
Alternator model: KTW5
Start system: Recoil/Electric
Empty load welding DC voltage: 65V
Rated welding current: 50A-180A
Welding load continuous rate: 50%
Welding work voltage: 20-30V
Adjust current: 80-180A
Exceation type: Controller exceation
Work type: 8hours
Fuel tank capacity: 12.5L
Continues running time: 6Hr
Engine:
Engine type: Single-cylinder, vertical, 4-stroke air-cooled diesel engine
Maxoutput engine: 9.5HP/3000rpm 10HP/3600rpm
Bore X Stroke: 86x72
Displacement Capacity: 411cc
Fuel consumption rat: ≤280g/kw. H
Fuel: 0# or -10# light diesel oil
Lubrication Oil Volume: 1.65L
Combustion System: Direct Injection
