Rated frequency (Hz) 50 60
Rated voltage (V) 230 240/120
Rated current (A) 21.7 22.9/45.8
Rated output power (kVA) 5.0 5.5
Rated rotation speed (rpm ) 3000 3600
DC output 12V-8.3A
Power factor cosφ 1.0
Phase number Single phase
Excitation mode AVR
Noise level dB (A)/7m (zero load ~full load ) 75~79
Overall dimension [mm (in)] (LxWxH ) 720x492x650(28.35x19.37x25.59)
Dry weight [kg (lbs)] 95(209)
Structure model Open-frame
Connection mode Transmission shaft rigid coupling
Engine model SD186F
Engine type Single cylinder, 4-stroke, air-cooled, direct injection, diesel engine
Displacement [cm3 (cu-in)] 418
Compression ratio 19: 1
Rated power [kW (HP)/rpm] 6.3(8.6)/3600
Rated rotation speed (rpm)
T. C. I with
Spark plug ----
Starting system Recoil starter /Eletrical Start
Rotation direction (view from wheel) Clockwise
Fuel type 0# (summer), -10# (winter) light diesel oil
Lube brand SAE10W30(above CC grade)
Low oil pressure alarm system With.
