Engine: PERKINS, 4008TAG2A
Charge alternator: 24V
Governor: Electrical
Generator: STAMFORD, LVI634E
Single bearing alternator IP 23
Insulation class H/H
Radiator 50 degree max with coolant cap
Skid and vibration isolators
Dry type air filter
Main line circuit breaker
24V battery and cable
Industrial muffler
User's manual
|
GEN-Set |
Dimension(L×W×H) |
Weight |
|
OpenType |
4700mm×2070mm×2420mm |
8892Kg |
|
SilentType |
9120mm×2438mm×2896mm |
14892Kg |
Voltage |
Hz |
Phase |
Powerfactor |
StandbyAMP |
StandbyRating
(KVA/KW) |
PrimeRating
(KVA/KW) |
|
400/230 |
50 |
3 |
0.8 |
1587 |
1100/880 |
1000/800 |
|
Manufacturer/Model |
PERKINS 4008TAG2A 4-cycle |
|
Cylinder/Arrangement |
8/ L |
|
Displacement |
30.561L |
|
BoreandStroke |
160mm×190mm |
|
Compressionratio |
13.6 :1 |
|
RatedRPM |
1500RPM |
|
Max.standbypoweratratedRPM |
985KW |
|
Frequencyregulation,steadystate |
± 0.25% |
|
Governor:type |
Electrical |
|
Exhaustgasflow |
200m³/min |
|
Exhaust temperature |
465 degree celsius |
|
Maxbackpressure |
816mm H2O |
|
Radiator&enginecapacity |
143L |
|
Maxwatertemperature |
101 degree celsius |
|
Thermostat |
71-85 degree celsius |
|
Manufacturer/Type |
STAMFORD/LVI634E |
|
Numberofphasepower |
3 |
|
Factor(CosPhi) |
0.8 |
|
Pole:number |
4 |
|
Bearing:number |
1 |
|
Coupling |
Direct |
|
Excitertype |
PMG |
|
lnsulation: class, temperature rise |
H/H |
|
protection |
IP23 |
China Power Machinery Co. Ltd, Modern Power Machinery manufacturer, leading supplier in China, is a corporation of complementary business units that design, manufacture, distribute and service generators and related technologies, including diesel generator, diesel utility vehicle, snow blower, riding lawn mower, snowmobile, golf cart etc., specially focused in power products.
Headquartered in Shanghai, China, belong to the Group who employs approximately 2, 500 people worldwide, which was awarded AAA(1) Credit Certification by the PRC Ministry of Commerce, Shanghai AAA Credit Freight Forwarder industry, Shanghai Excellent Clearance AA Credit Enterprise, also rated to be Shanghai Famous Brand Service Supplier and Shanghai Key Enterprise, which enable the company to be listed on top 14 of nation-wide enterprises. Certified by ISO9001: 2008, we won the award of premium partner of Bank of China.
We have established good co-operative relationship with China Customs., China Commodity Inspection Department and other related departments, achieves an Annual turnover of 0.64 billion US$. Innovation, Quality Control and Cost Control are our main advantages, Global Quality Assurance for the Diesel Genset, Cummins is one important feature, for other Diesel Generators which combined with other brand engine (also they are worldwide fame), Power guarantee: If Compared with other China Factories, you will find our products:
1. Better Price if the Same Quality
2. Better Quality if the Same Price
We sincerely hope establishing long and friendly business relations with clients from all over the world. Our goal is not just providing product, but also providing a complete solution including product design, tooling, fabrication and service for our customers to achieve their upmost satisfaction.
We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with the good quality at the reasonable price.
