50Hz
Prime power: 300KW/375kVA
Standby power: 330KW/412kVA
60Hz
Prime power: 350KW/438kVA
Standby power: 500KW/400kVA
Genset parameters:
1. Power factor: COSΦ =0.8lagging
2. Noise level: 80-100dB
3. Start-up mode: Electric
4. Fuel consumption: 80L/H(50Hz) 100L/H(60Hz)
5. Rated currency(AMPS): 627
6. Protections for low oil pressure, high water temperature, over-speed, over-current
7. Package dimension: 3250mm*1100mm*1850L*W*Hweight: 3200Kg
Engine:
1. Cummins engine model: NTA855-G7
2. Power: 369KW(50Hz)
3. Rated Voltage: 380/220V
4. Cylinders/ layout: 6L
5. Voltage Control: AVR
6. Insulation: H
7. Start-up mode: DC24V electric start
8. Protection: IP21
9. Overload: 110%
10. Displacement: 14L
11. Inter-Cooling: Air inter-cooling
12. Steady Speed Droop ≤ 1%
13. Speed-Governing: Electric
Alternator parameters:
1. Stamford modela: HCI444F or Marathon MP-280-4
2. Power: 320KW (Stamford)/280KW(Marathon)
3. Rated voltage: 380/220V
Singfo, one of the leading worldwide suppliers of power generators, is located in beautiful Zhujang Delta of China with the establishment in 1996. The Company has an office overseas as well as fourteen branches all over the country with more than four-hundred staff members through its years of development, of which has formed a chain from production. Sales, maintenance to customer service.
To meet its client's requirements, Singfo has set up and implemented a well-regulated management system targeting towards competitive price, excellent quality and reputable customer service in long-run. The Company has fostered a team focused on self-improvement, all of whom are rich in experience, professional at technology and dutiful to their work. Moreover, our services also cover technical output, scientific research, project design and construction.
