50Hz
Prime power: 280KW/350kVA
Standby power: 310KW/388kVA
Genset parameters:
1. Power factor: COSΦ =0.8lagging
2. Noise level: 72-75dB
3. Start-up mode: Electric
4. Fuel consumption: 76L/H(50Hz)
5. Rated currency(AMPS): 589
6. Protections for low oil pressure, high water temperature, over-speed, over-current
7. Package dimension: 4200mm*1500mm*1900L*W*Hweight: 3790Kg
Engine:
1. Cummins engine model: NTA855-G4
2. Power: 350KW(50Hz)
3. Rated Voltage: 380/220V
4. Cylinders/ layout: 6L
5. Voltage Control: AVR
6. Insulation: H
7. Start-up mode: DC24V electric start
8. Protection: IP21
9. Overload: 110%
10. Displacement: 14L
11. Inter-Cooling: Air inter-cooling
12. Steady Speed Droop ≤ 1%
13. Speed-Governing: Electric
Alternator parameters:
1. Stamford modela: HCI444E or Marathon MP-280-4
2. Power: 280KW(350kVA)
3. Rated voltage: 380/220V
