Rated frequency [Hz] 50 60
Rated voltage [V] 230 240/120
Rated current [A] 7.4 8.3/16.7
Rated output power [KVA] 1.7 2.0
Max output power [KVA] 2.0 2.3
Rated rotation speed [rpm] 3000 3600
DC output 12V8.3A
Power factor [cos] 1
Phase number Single phase
Noise level [dB(A)@7m] 78-79
Overall dimension (LxWxH) [mm ] 660x480x540
Dry weight [kg] 53 recoil 60 electric
Structure type Open-frame type
Excitation mode Self-excitation brushless
Engine model SH170F/E
Engine type Single cylinder, 4-stroke, air-cooled,
Direct injection, diesel engine
Displacemen [ml (cu. In)] 211 (25.51)
Compression ratio 20: 01
Rated power [KW (Hp)/rpm] 2.5 (3.4)/3000 2.8 (3.8)/3600
Starting system CL: Recoil starter E: Electric starter
Rotation dircetion (View from flywheel) Clockwise
Fuel 0# (summer) or -10# (winter) light diesel
Lube SAE10W30 (above CC grade)
Low oil pressure alert system With
Zhejiang Zeteng Machinery Co., Ltd. is a professional mechanical and electrical equipment enterprise located in Taizhou China belongs to SANYOU HOLDING GROUP Co., Ltd. As a reliable supplier in Power equipment industry, we have been exporting a variety of standard and custom designed gasoline engine, gasoline generator, and gasoline waterpump, compactor, diesel engine, diesel generator, diesel waterpump to worldwide market with extensive experience. We have abundant capital and handle our own product development, production and after- sales service.
SMD means super max design and has good reputation for its persistent guideline regarding credit and quality as the uppermost and offering customers the best suitable products and well-pleasing service with business in more than 20 countries such as Europe, America, Southeast, Middle East and Africa, etc. It operates an advanced production line with whole set of inspection and testing equipment and a yearly capacity of 150, 000 sets of machines. And we use a combination of traditional skills and new technology to maintain consistent quality all across the production range.
Our company has gain EPA, CE, GS certification for products and ISO9001 for company management. We always follow the principle of "Quality is the life, and customer is first. " SMD people sincerely hope to cooperate with all friends all over the world hand in hand to create a common glorious tomorrow.
