Company Frofile:
Guangzhou Weilida Machinery&Electronic Co., Ltd. Founded in 1994 with a big OEM factory specialized in manufacturing, sales and leasing Services. We can provide Diesel Generator Set, Moving Tailer Generator, Silent Generator Electric Generator, Natural Gas Generator under the famous brand of CUMMINS, DEUZT, CATERPILLAR, SHANGCHAI(SEDC), YUCHAI, with power ranging 0.65-3000kVA; AC alternator under the brand of STAMFORD, MARATHON, FARADAY and Siemens. We also offer spare parts for SFH, SEDC and HINO.
Engine Features:
1) Super power, PT fuel system, ultra-high injection pressure, sufficient combustion, low fuel consumption and good economic performance
2) Replaceable wet cylinder sleeves, effective cooling system, good spare parts commonality, high product serialization, easy maintenance and low failure.
3) High-strength alloy cast iron with good rigidity, small vibration, low noise, good reliability and durability
4)Professional configuration, best quality, mature product, global reputation, and wide industry application
5) Electric controlled high-pressure fuel system to make sure full fuel combustion, low consumption, and engine in the best running status.
6) High-pressure fuel system, even fuel injection, able to reduce the loss of additional power
Alternator Features:
Brand Stamford, Simens, Marathon, Farady at option
AVR model: R448 V50
Number of phase: 3
Power factor (Cos Phi): 0.8
Altitude: ≤ 1000 m
Overspeed: 2250RPM
Number of Pole: 4
Exciter type: AREP
Insulation class: H
Voltage regulation: ± 0.5%
Sustained short circuit current 300% (3 IN): 10s
Total harmonics (TGH/THC): < 3.5 %
Wave form NEMA = TIF: < 50
Wave form i. e. C. = THF: < 2%
Bearing: Single
Coupling: Direct
Control system:
Automatic alarm system: The unit has the acousto-optics alarm system and arrestor for any situation as the start defeat, the water is over temperature, the oil pulls down, over speed, over load and over current
1. Operation display:
2. Unit voltage, tri-phase load current and frequency display
3. Water temperature, oil pressure display
4. Fuel level, fuel temperature display
5. Audible and visual alarm lamps and buzzers
6. Starting system: DC alternator is used to start engine
7. Short circuit protection: MCCB air switch
8. Cooling system: Combined cooling water tank fitted to meet the requirement of radiation at ambient
Temperature 40° C
9. Filter system: Oil, fuel and air filter
10. Accessories: Exhaust elbow, bellow, muffler
Technical support & Service:
Standards:
Generator sets: ISO9001-2000,
ISO9001-2008, JB/T 1403-1999,
GB/T 12501-1990
Pre-sales Guidance:
Weilida Co. Professional technician responsible for users' technical advisory question and make sure the configuration, features, optional items etc.
Testing:
All Gensets are strictly tested with loads before delivery, including load test, operating system and protection system, all details will be recorded in the test report.
Maintenance & Accessories:
Weilida Co. Has a team of experienced engineers, special tools and testing equipment complete full range of accessories reserves customer better.
Service & Tenet:
Customers supreme, Service-oriented All-day, all-round, dedicated to customer service.
Service:
24 hours after-sale service teleline; Within guarantee period if spare parts impaired, free offer parts (Within factory standard parts) and technonical.
Genset model |
Standby power |
Prime power |
Fuel cons. 100% (g/kw.h) |
Engine model |
Cyl. |
Bore/ Stroke |
Dimension |
Weight |
KW |
KVA |
KW |
KVA |
mm |
LxWxH(mm) |
kg |
DC20 |
20 |
25 |
22 |
28 |
≤209 |
4B3.9-G2 |
4 |
102/120 |
1720x740x1120 |
780 |
DC30 |
30 |
38 |
33 |
41 |
≤209 |
4BT3.9-G2 |
4 |
102/120 |
1900x820x1480 |
850 |
DC50S |
50 |
63 |
55 |
69 |
≤210 |
4BTA3.9-G2 |
4 |
102/120 |
1720x850x1400 |
1050 |
DC90 |
90 |
113 |
99 |
124 |
≤210 |
6BT5.9-G2 |
6 |
102/120 |
2050x850x1500 |
1350 |
DC100 |
100 |
125 |
110 |
138 |
≤210 |
6BTA5.9-G2 |
6 |
102/120 |
2050x850x1400 |
1380 |
DC120 |
120 |
150 |
132 |
165 |
≤209 |
6BTAA5.9-G2 |
6 |
102/120 |
2150x850x1500 |
1485 |
DC150 |
150 |
188 |
165 |
206 |
≤207 |
6CTA8.3-G2 |
6 |
114/135 |
2400x1000x1500 |
1880 |
DC180 |
180 |
225 |
198 |
248 |
≤207 |
6CTAA8.3-G2 |
6 |
114/135 |
2500x1000x1500 |
1950 |
DC200 |
200 |
250 |
220 |
275 |
≤205 |
6LTAA8.9-G2 |
6 |
114/145 |
2600x1000x1500 |
2150 |
DC250 |
200 |
250 |
180 |
225 |
≤192 |
NT885-GA |
6L |
140/152 |
2890x1100x1652 |
2795 |
DC303 |
242 |
303 |
220 |
275 |
≤200 |
MTA11-G2A |
6L |
125/147 |
2995x1100x1652 |
2975 |
DC344 |
275 |
344 |
250 |
313 |
≤195 |
NTA855-G1A |
6L |
240/152 |
2995x1100x1652 |
3050 |
DC358 |
286 |
358 |
260 |
325 |
≤188 |
MTAA11-G3 |
6L |
125/147 |
2995x1100x1652 |
3050 |
DC413 |
330 |
413 |
300 |
375 |
≤200 |
NTA855-G2A |
6L |
140/152 |
3090x1100x1652 |
3200 |
DC481 |
385 |
481 |
350 |
438 |
≤205 |
NTAA855-G7A |
6L |
140/152 |
3160x1100x1700 |
3255 |
DC495 |
396 |
495 |
360 |
450 |
≤207 |
KTA19-G3 |
6L |
159/159 |
3160x1100x1700 |
3257 |
DC550 |
440 |
550 |
400 |
500 |
≤207 |
KTA19-G4 |
6L |
159/159 |
3560x1345x1965 |
4100 |
DC625 |
500 |
625 |
450 |
563 |
≤207 |
KTAA19-G5 |
6L |
159/159 |
3560x1345x1965 |
4165 |
DC660 |
528 |
660 |
480 |
600 |
≤206 |
KTAA19-G6A |
6L |
159/159 |
3560x1345x1965 |
4200 |
DC688 |
550 |
688 |
500 |
625 |
≤206 |
KTAA19-G6A |
6L |
159/159 |
3560x1345x1965 |
4305 |
DC756 |
605 |
756 |
550 |
688 |
≤216 |
KTA38-G |
12V |
159/159 |
3580x1538x1965 |
4600 |
DC880 |
704 |
880 |
640 |
800 |
≤216 |
KTA38-G2 |
12V |
159/159 |
3580x1538x1965 |
4650 |
DC1000 |
800 |
1000 |
720 |
900 |
≤203 |
KTA38-G2A |
12V |
159/159 |
3650x1638x2040 |
4685 |
DC1100 |
880 |
1100 |
800 |
1000 |
≤205 |
KTA38-G5 |
12V |
159/159 |
4450x1638x2040 |
7200 |
DC1375 |
1100 |
1375 |
1000 |
1250 |
≤202 |
KTAA38-G9A |
12V |
159/159 |
5560x1900x2300 |
11000 |
