All types of generators can be supplied.
| Model | LDG5500E | |
| Rated Frequence(HZ) | 50 | 60 |
| Max.AC Output(KVA) | 5.0 | 5.5 |
| Rated AC Output(KVA) | 4.2 | 4.6 |
| Rated AC Voltage(V) | 110;120;220;110/220;120/240 |
| Rated Current(A) | 36.6/18.3 | 38.4/19.2 |
| DC Output(V/A) | 12/8.3 |
| Phase Number | Single Phase |
| Power Factor | 1.0 |
| Pole Number | 2 |
| Insulation | B |
| Excitation Mode | Brushless,Self-excitation |
| Engine Model | LK186FA |
| Engine Type | Forced air-cooled,4-stroke,Single Cylinder Diesel Engine |
| Cylinder Number-Bore*Stroke(mm) | 1-86*72 |
| Compression Ratio | 19:1 |
| Rated Rotation Speed(rpm) | 3000 | 3600 |
| Rotation Direction | Clockwise |
| Cooled System | Forced air-cooled |
| Starting System | Electric Starter |
| Low Oil Pressure Alert System | With |
| Oil | SAE10W30(Above CD Grade) |
| Lube Type | Pressure,Splash |
| Lube oil Capacity(L) | 1.65 |
| Fuel | 0# (Summer) -10# (Winter) -35# (Fierce Cold)
Light Diesel |
| Fuel Tank Capacity(L) | 15 | 15 |
| Starter Motor Capacity(V-KW) | 12V - 0.8KW |
| Charger Set Capacity(V-A) | 12V - 3A |
| Battery Capacity(V-Ah) | 12V-22AH |
| Structure Type | Open-frame |
| Noise Level(7m)dB(A) | 84 | 85 |
| Displacement (ml(cu.in)) | 406(24.78) |
| Net Weight(kg) | 96 |
| Gross Weight(kg) | 98 |
| Continuous Operating Hours(h) | 8.5 | 8 |
| Dimension(L*W*H)(mm) | 730*500*605 |
