Model: KDG6000SE
Rated frequency(Hz): 50
Rated output(KVA): 5.0
Phase: Single
Power factor: 1.0
Rated voltage(v): 220(230),
Rated DC Output(v/a): 12/8.3
Start system: Electric starter
Fuel tank capacity(l): 12.5
Operating hour(h): 5.5
Engine model: KD186FAE
Engine type: Vertical, single-cylinder, 4-stroke, air-cooled
Engine speed(RPM): 3000
Engine outputHP): 10
Alternator model: 2-pole, brush(less), self-excitation
Operating noise level(at 7m): 70
Battery capacity (Ah): 20-24
Voltage regulation: ± 1% under balance load
Net weight(kg): 175
Gross weight(kg): 185
Dimension(mm): 920x520*740
Package Dimension(mm): 955*565*760
