We are Western Union Electric Industrial Co., Ltd., committed to providing customers with high-quality power products and perfect service system, now mainly is generators and pumps.
One of the important partners of the British NUT industry group, the British Perkin power group, the Stanford motor, the United States Cummins power, (the world's four big power manufacturers) in China.
FYI:
This is our website: HTTP: //nutunion. En. Made-in-China. com/
|
Model |
NUT-20TA3 |
|
Generator |
Rated frequency |
Hz |
50 |
|
Rated output |
KVA |
20 |
|
KW |
16 |
|
Rated voltage |
V |
230/400 |
|
Rated current |
A |
28.8 |
|
Rated rotation speed |
r/min |
1500 |
|
Phase no./Excitation mode |
Three phase/Self-excitation and constant voltage (with AVR) |
|
Power factor (COS φ) |
0.8(lag) |
|
Insulation grade |
H |
|
Pole number |
4 |
|
Engine |
Model |
NUT4805T |
|
Type |
Four cylinder, 4_stroke, direct injection |
|
Cylinder No.-Bore x Stroke |
mm |
4_85 x 95 |
|
Displacement |
L |
2.156 |
|
Compression ratio |
18:1 |
|
Rated power |
KW(r/mm) |
17.6 /1500 |
|
Fuel type |
0#(summer),_10#(winter),_35#(cold)light diesel |
|
Lube oil type |
Above CD grade, SAE 10W30 or 15W40 |
|
Fuel consumption |
g/kw.h |
≤210 |
|
Fuel tank capacity |
L |
50 |
Bunkers
Continuous running time |
h |
10 |
|
Set |
Overall dimension LXWXH |
Mm |
1600 x 800 x 1000 |
|
Net weight |
Kg |
680 |
|
Starting mode |
12V electric starting |
|
Noise at zero load |
dB(A)/1m |
70 |
|
Noise at rated load |
dB(A)/7m |
62 |
|
Structure type |
silent |
|
|
|
|
|
|
Western Union (Foshan) Industrial Co., Ltd.Committed to providing customers with high-quality power products and perfect service system, our products including diesel generators, gasoline generators, pumps, generator welders, construction engineering machinery.Customers throughout the multiple industry sectors such as power supply, railways, telecommunications, mobile, banking, oil field, traffic, city, hotel, household, hospital, etc...
The company has industry-leading research and development technology, strong comprehensive strength, With more than 30000m2 of large factory, warehouse and office building, Mainly developes own-brand productions and be the sales agent for the imported brand power products.
With outstanding production capacity and high quality control, in 2008 we became one of the important partners of the British NUT industry group, the British Perkins power group, the Stanford motor, the United States Cummins power, (the world's four big power manufacturers) in China.We passed the ISO9001:2008, CCC, CE TUV certification.Products are exported to many countries around the world.
Sticking to the principle of providing customers with high quality affordable energy products gains high endorsement from partners both at home and at abroad.
"The quality is the life of the enterprise" is our everlasting goal.Western Union Industrial establishes a good long-term relations of cooperation with the general channel distributors and retailers in the world, to provide users with high quality and reliable power products and make the perfect solution.
We look forward to cooperate with the customers and common progress, to achieve mutually beneficial and win-win goal!
