Model & Specification: (50Hz, 1500RPM, 400/230V Adjustable, 0.8 Lagging power factor)
GENSET MODEL PRIME POWER STANDBY POWER ENGINE MODEL DIMENSION (LXWXH) mm WEIGHT (kg)
KVA KW KVA KW
HBC176 200 160 220 176 NT855-GA 3000X1000X1600 2900
HBC200 225 180 250 200 NT855-GA 3000X1000X1600 3100
HBC220 250 200 275 220 NT855-GA 3000X1000X1600 3100
HBC240 271 217 300 240 NT855-GA 3000X1120X1600 3150
HBC250 285 228 312.5 250 NTA855-G1A 3000X1000X1600 3200
HBC275S 312.5 250 343.75 275 NTA855-G1A 3000X1120X1600 3250
HBC275 312.5 250 343.75 275 NTA855-G1B 3000X1000X1600 3300
HBC286 325 260 357.5 286 NTA855-G2A 3000X1000X1600 3300
HBC310S 350 280 387.5 310 NTA855G2A 3000X1000X1600 3400
HBC310 350 280 387.5 310 NTA855-G4 3200X1120X1600 3500
HBC330S 375 300 412.5 330 NTAA855-G7A 3250X1380X1600 3600
HBC360S 400 320 450 360 NTAA855-G7A 3450X1380X1600 3800
Performance Feature
Performance Feature
1)Engine and alternator shall be mounted on a same frame steel skid.
2)Built-in damper for anti-vibration.
3)Small size, low weight, easy to operating, installation and maintenance.
4)World most famous brand diesel engine.
5)World famous brand AC alternator: Stamford, Marathon, Leroy Somer, MVC.
6)Advanced and reliable control module: Key start, Auto start, Remote control by PC with RS232/485
7)Full range protect function and alarm shutdown feature.
Alternator Feature
1)Brush-less, 4 poles, rotation magnet.
2)IP21-23(NEMA1) enclosure is standard for all industrial alternators.
3)The insulation system is Class H
4)Simple installation and maintenance, with easy access to terminals, rotating diodes and coupling bolts.
5)Wide range of flange adaptors and single bearing disc coupling.
6)Standard 2/3 pitch windings avoid excessive neutral currents
7)AVR auto voltage regulator, auto exciter, auto adjustment
Standard Accessory
Common steel base frame, Circuit breaker, Damper, Exhaust silencer, Flexible pipe, Battery and connecting wires, Operation manual and document.
Optional Accessory
Engine coolant and oil heater, Alternator space heater, Cooling for heat exchanger, Control system with RS232/485 communication interface, Battery charger by main supply, Fuel-water separator, Daily fuel tank, ATS & paralleling system, Soundp
Honny Genset Equipment Engineering Co., Ltd. Was founded in year 1992, and has been one of the largest generator manufacturers in China. We specialize in the assembly, design, sales, installation, maintenance, and service of Cummins, Perkins, Deutz, Volvo Penta, Daewoo series generator sets with power ranging from 10-2500kVA. We believe that it is our assurance of quality and exceptional communication skills as well as our competitive prices and professional service, that will always mean your best choice.
With the great efforts and developments of over 15 years, Honny now employs over 1000 employees, including 100 in management positions, 120 technical personnel, over 200 engineers, 200 maintenance and service personnel, and over 300 salesmen. Honny now operates over 32 branches and offices, throughout the largest cities in China. Our assembly capacity is over 10, 000 sets per year.
At present, Honny has established a strategic cooperation with many world famous companies and has established OEM partnerships with Cummins, Perkins, Daewoo, Deutz, and Volvo Penta diesel engines as well as Marathon, Leroy Somer, Stamford, and MVC alternators. In past year 2005 and 2006, Honny was the No. 1 and largest OEM manufacturer for Cummins Diesel Engine and Marathon Alternator in China.
HONNY runs in accordance with the ISO9001: 2000 quality system, and design, assembly, sales and after-sales service for 10-4000KW generator sets, ATS, paralleling systems and low voltage switchgear systems. Our products are widely used in building, plant workshops, the hospital industry, oil fields, roads and railway systems, marine, military equipment, mining etc.
Quality, Price and Service are regarded as the number one priority for all Honny's staff, and we dedicate ourselves to this promise. Honny gained the ISO9001: 2000 quality certificate at the end of 2004, and also gained the Telecom Entrance License Certificate of PRC Information Industry Ministry in May of 2005. In July 2005, Honny's products were tested and checked by the National Generator Sets Inspection Center and gained the quality assurance certificates for all products. At the same time, Honny series products were also tested by the China Middle-Light Product Quality Assurance Center and gained the Quality Certificate for all products in our ever-expanding series.
