Main Specifications:
Rated Output: 8KW- 24KW
Rated Voltage: 400V/230V
Rated Frequency: 50/60Hz
Starting Type: Electric starting
Cooling Method: Closed water cooled
Trade Mark: YONGHENG
Standard: ISO9001, CE, EPA
Payment: T/T or L/C
Packing: In wooden cases or plywooden case
Origin: Fujian, China
TECHNICAL DATA(50HZ)
|
GENSET MODEL
|
GF3-8
|
GF3-10
|
GF3-12
|
GF3-16
|
GF3-20
|
DIESEL ENGINE MODEL
|
YSAD 380G
|
YD 480G
|
Y 485G
|
YSD 490G
|
Y 4100G
|
Engine characters
|
Water-cooled, in line, 4-cylinders, 4-cycle, direct injection, 1500rpm
|
Bore/Stroke
|
80/90
|
80/90
|
85/90
|
90/100
|
100/115
|
Rated output(KW)
|
10
|
13.5
|
16
|
21
|
25
|
Fuel consumption
(g/kw. hr)
|
< 247
|
< 250.2
|
< 248.9
|
< 247.5
|
< 237
|
Lube consumption
(g/kw. hr)
|
< 2.72
|
Compression ratio
|
18
|
Starting model
|
Electric(12V)
|
ALTERNATOR MODEL
|
YH-164B
|
YH -164C
|
YH-164D
|
YH-184E
|
YH -184F
|
Rated power(KW)
|
8
|
10
|
12
|
16
|
20
|
Voltage(V)
|
400/230
|
400/230
|
400/230
|
400/230
|
400/230
|
Current(A)
|
14.4/34.8
|
18/43.5
|
21.7/52.2
|
27.1/65.2
|
36/86.7
|
Frequency(HZ)
|
50
|
Power factor( cosΦ )
|
0.8/1.0
|
Dimensions(L × W × H)mm
|
1760 × 800 × 950
|
1860 × 800 × 950
|
1860 × 800 × 950
|
2050 × 880 × 1050
|
2150 × 880 × 1050
|
Net weight(kg)
|
650
|
700
|
750
|
800
|
900
|
TECHNICAL DATA(60HZ)
|
GENSET MODEL
|
GF3-8
|
GF3-10
|
GF3-12
|
GF3-15
|
GF3-20
|
GF3-24
|
DIESEL ENGINE MODEL
|
YSAD 380G
|
Y 385G
|
YD 480G
|
Y 485G
|
YSD 490G
|
Y 4100G
|
Engine characters
|
Water-cooled, in line, 4-cylinders, 4-cycle, direct injection, 1800rpm
|
Bore/Stroke
|
80/90
|
85/90
|
80/90
|
85/90
|
90/100
|
100/105
|
Rated output(KW)
|
12
|
14
|
17
|
19
|
25
|
30
|
Fuel consumption(g/kw. hr)
|
< 247
|
< 262.5
|
< 250.2
|
< 248.9
|
< 247.5
|
< 237
|
Lube consumption(g/kw. hr)
|
< 2.72
|
Compression ratio
|
18
|
Starting model
|
Electric(12V)
|
ALTERNATOR MODEL
|
YH-164B
|
YH -164C
|
YH-164D
|
YH-184E
|
YH -184F
|
YH -184G
|
Rated power(KW)
|
8
|
10
|
12
|
15
|
20
|
24
|
Voltage(V)
|
400/230
|
400/230
|
400/230
|
400/230
|
400/230
|
400/230
|
Current(A)
|
14.4/34.8
|
18/43.5
|
21.7/52.2
|
27.1/65.2
|
36/86.7
|
43.1/104
|
Frequency(HZ)
|
60
|
Power factor( cosΦ )
|
0.8
|
Dimensions(L × W × H)mm
|
1760 × 800 × 950
|
1760 × 800 × 950
|
1860 × 880 × 950
|
1860 × 880 × 950
|
2050 × 880 × 1050
|
2150 × 880 × 1050
|
Net weight(kg)
|
650
|
700
|
750
|
800
|
900
|
1000
|
Fuan qinfeng electric motor Co., Ltd. is a leading enterprise in the national export base of mechanical and electrical products. We specialize in manufacturing water pumps, motors, alternators, gasoline and diesel generating sets. Our products are well received in international market for their high quality and preferential prices. We always regard "customers the first, credit above all" as our aim and carry forward the spirit of "reality, reform, and novelty tribute". We pay much attention to the quality, perfecting the management and developing the enterprise.
We have abundant fund, strong technical capabilities and perfect testing systems. We can design and develop products by ourselves. Now, we implement according to ISO9001 system. Our products include more than 10 series and 200 specifications, including yc/ycl/yl series capacitor starting asynchronous motors, y/y2 series three phase motors and aluminum shell motor with ms/mc/my/ml series. We also supply st/stc series alternator, brushless alternators and diesel generating sets. Our products sell well in southeastern Asia, the Middle East, South Africa and Europe. Our company has passed the evaluations of ISO9001: 2000, CE and RoHS certifications.
We hope to establish good relationships with you. Please feel free to contact us for further information.
