Deutz diesel generator
Genset Model: RD-25DS
Frequency (Hz): 50
Rated output(W/KVA): 20/25
Rated voltage(V): 400/230
Rated current(A): 36.1
Rated speed(r/min): 500
Overall dimension(L*W*H)(mm): 2300*915*1180
Dry weight(Kg): 1090
Noise level dB(A)/7m: 75
Alternator Model: LEROYSOMER LSA 42.2 M7
Frequency(Hz): 50Hz
Insulation class: H
Excitation system: Shunt
Winding pitch: 2/3
Power factor: 0.8lag
Drip proof: IP 23
TGH/THC: < 4%
Wave form: TIF: < 50
Wave form: THF: < 2%
Engine model: DEUTZ D226B-3D
Engine type: In-line, forced water cooling, 4-stroke diesel engine
Air Intake Way: Turbocharged
Bore x stroke (mm): 3-105*120
Max. Power kW/(r/min): 33/1500
Prime fuel consumption(g/kW. H): 208
Starting system: 24V electric starter
Standard Accessories
Brand new single-bearing LEROYSOMER brushless alternator, DEUTZ engine
Radiator with engine driven fan mounted on skid
Electric starter
Battery Charger
Set mounted standard mechanical control panel
Industrial silencers with flexible connects and elbow
Acid battery
MCCB (Breaker)
Base fuel tank for 8 hours' continuous operation
Steel base-frame against vibration
Anti-vibration mounted
Test report of generator, Set of drawings and O&M manuals
Standard tools kit
Optional Accessories
It is necessary to pay additional if you need these accessories as follows:
SMARTGEN 6120
The 6120 is a single diesel generator set controller. It is able to realize the automatic start and stop, self-protection and etc.
Damageable spare parts such as air filter, fuel filter, oil filter, cylinder head gasket, piston, piston ring, AVR.
Power by Power by Deutz Engines(30-150KVA) Three-phase, Power factor 0.8, 50Hz@1500PRM |
Genser Specification 480/227v |
Engine Model |
Displacement (L) |
Dimension L*W*H (mm) |
Weight (kg) |
Genset Model |
KVA |
KW |
Prime |
Stanby |
Prime |
Stanby |
RD-30D |
30 |
34 |
24 |
27 |
D226B-3D |
N |
1620× 780× 1200 |
780 |
RD-45D |
45 |
50 |
36 |
40 |
TD226B-3D |
TC |
1750× 780× 1200 |
810 |
RD-60D |
60 |
66 |
48 |
53 |
TD226B-4D |
TC |
1950× 750× 1650 |
950 |
RD-80D |
80 |
88 |
64 |
70 |
TD226B-6D |
TC |
2170× 850× 1700 |
1210 |
RD-90D |
90 |
100 |
72 |
80 |
TD226B-6D |
TC |
2170× 850× 1700 |
1420 |
RD-100D |
100 |
110 |
80 |
88 |
TBD226B-6D |
TCA |
2170× 850× 1700 |
1450 |
RD-120D |
120 |
132 |
96 |
106 |
TBD226B-6D |
TCA |
2170× 850× 1700 |
1480 |
RD-150D |
150 |
165 |
120 |
132 |
TBD226B-6D5 |
TCA |
2230× 840× 1700 |
1580 |
Alternator option: Stamford, Leroysomer, Marathon or Chinese brand |
