Our company supply high quality: Grid tie inverter, Grid-connected inverter, Power inverter, On grid inverter, Solar inverter, Solar on grid inverter, Wind on grid inverter, PV inverter, Hybrid inverter. And high efficiency: Grid tie inverter, Grid-connected inverter, Power inverter, On grid inverter, Solar inverter, Solar on grid inverter, Wind on grid inverter, PV inverter, Hybrid inverter And low price: Grid tie inverter, Grid-connected inverter, Power inverter, On grid inverter, Solar inverter, Solar on grid inverter, Wind on grid inverter, PV inverter, Hybrid inverter.
1. Directly connected to the solar panels (do not need to connect the battery)
2. AC 0 angle with high precision auto-detection
3. Automatic Sensing Function Solar Luminosity
4. Constant Current, Constant Power
5. Automatically Shut Down When The Power Output Of a Fault
6. Stack Multiple Machines
7. High-Frequency High Conversion Rate
Grid-series models |
200W |
300W |
400W |
500W |
600W |
800W |
1000W |
Recommend use solar panels |
320Wp |
420Wp |
520Wp |
620Wp |
720Wp |
1050Wp |
1250Wp |
DC Maximum Input Power |
300W |
400W |
500W |
600W |
700W |
900W |
1200W |
DC maximum voltage |
VpvDC30.2VDC |
DC voltage range |
Vpv 10.5V~28VDC |
Maximum output power factor |
99% |
Maximum input current |
15A |
20A |
25A |
30A |
40A |
45A |
65A |
AC output power |
200W |
300W |
400W |
500W |
600W |
800W |
1000W |
AC maximum output power |
200W |
300W |
400W |
500W |
600W |
1000W |
Anti-voltage protection |
Fuse |
AC standard voltage range |
90V-140/180~260VAC |
AC frequency range |
55Hz~63Hz/ 45Hz-53Hz |
Output current total
harmonic distortion |
THDIAC <5% |
Phase |
<1% |
Islanding protection |
VAC;f AC |
Output short circuit protection |
Current-limiting |
Show |
LED |
Standby Power |
<2W |
Night Power |
<1W |
Ambient temperature range |
-25 ~60 |
Humidity |
0~99%(Indoor Type Design) |
Waterproof |
Indoor Type Design |
Electromagnetic Compatibility |
EN50081.part1 EN50082.part1 |
Power System Disturbance |
EN61000-3-2 EN60950-1 |
Network test |
DIN VDE 1026 |
Yueqing Sandi Electric Co., Ltd specialized in the new energy source and electrical source scientific research, development, manufacture and service had surpasses for 10 years of electrical source field; Which recognized by widely customers according to entirely varieties, high quality and service first. At present, the researched products by our company basically contain the best product at home and abroad, which delegated the top level of electrical source manufacture all over the world. The main products are: PV Grid-Connected Inverter, Solar Inverter, PV Solar Pumping Inverter, Water Pumping Inverter, Grid Tie Inverter, On Grid Inverter, Solar pumping inverter, Wind Turbine Controller, Solar Charge Controller, Pure Sine Wave Inverter, Off-Grid Inverter, power Inverter. The products of company are widely applied in fire fighting, construction, industry, new energy source, civilian use, finance, business tax, electric power, medical treatment, aviation, automatically control system of war industry and national heavy engineering project.
SANDI Electric Company insist on technology as forerunner, keep long-term, good research cooperation with all universities; Fetch in and absorb international advanced technology, built strictly quality control system.
We will take the work objective of "unremitting exploration, endeavor and innovation, honesty and dedication, perfect and practicality" and quality guideline of "criterion management, intensive manufacture, quality first, service with all hearts". Seek excellence, value innovation!
We will ceaselessly struggle and create refulgence with you together.
