Customized Design Ozone Generator Water Treatment

Customized Design Ozone Generator Water Treatment
Price: US $ 23000-31000/Piece
Trade Terms: FOB,CIF,EXW
Min Order: 1/Piece
Pay Type: L/C,T/T
customized design ozone generator water treatment



Feature- RO Water Treatment Plant:

1. Auto-check conductance display guarantee watching water quality.

2. Multi-media beforehand filter increases the capacity of water treatment.

3. Intelligent design circuit equipment auto stop and run when high or low water level.

4. RO membrane auto wash and manual wash, which can protect RO membrane easily.

5. Adopting S. S304 with opening design, clear process and convinient maintenance.

6. Safe and reliable electrical system design equipment auto stop protection when open circuit, short circuit and creepage.

7. Adopting high-efficiency active carbon filter which can wipes chlorine of raw water, protect RO membrane and adjust the taste.
Multi-medium filter: The equipment is a hermetically sealed chamber made of 1Cr18NiTi stainless steel which is set inside gritted rod, therefore get filtrated and clean.

Active carbon filter: This filter is designed for drinking water treatment. It can clear away alien color and foreign substance from the water and can remove heavy metal such as Mercury, Lead, Cadmium, Zink, Iron, Manganese, Chromium and Hydrogenate, Sulfide, Residual chlorine and other polymer organic compounds.

Sodion filter: This exchanging device is used for reducing the hardnes of hard water.

Ro plant:

1) Adopts RO membrane from VONTRON, which can remove 99.7% inorganic salt, heavy metal ion and completely get rid of colloid, microbiology organic materials, germ, protozoa, pathogens, bacteria, inorganic chemical and so on.
2) No need to add any chemicals, stable pure water quality, and no pollution drained, low produce cost.
3) Equipped with pretreatment system, such as active carbon absorption filter and refined quartz sand filter
4) 304 stainless steel rack and pipe accessories connection.
5) Equipped with auto pressure protection system and on -line monitor.
6) Automatically and manually wash RO membrane. Also the design of washing the RO membrane is by chemical solution (citric acid or sodium hydroxide optional)

Main Technical Data- RO Water Treatment Plant:

ModelCapacity(T/H)Power(kw)rate of desalinationInlet diameterPipe DIA of ConcentrationOverall Dimension(mm)Weight(KG)
RO-1000A1.05.3>99.5DN32DN321600*800*18001500
RO-2000A2.07.0>99.5DN32DN322600*800*18001800
RO-3000A3.08.5>99.5DN32DN323600*1800*18002500
RO-5000A5.013>99.5DN40DN402600*900*20003200
RO-10000A1026>99.5DN50DN503600*1200*17005000



Terms:                                                                       1. The price is FOB Zhangjiagang port; T/T, 30% deposit in advance, the balance of 70% prior to the delivery out of factory.
2. Packing: Wooden Case and PE film.
3. Working time: 40 days after receiving 30% deposit of total amount of contract or irrevocable L/C at sight.
4. Warranty: 2 years guarantee and life-long technical support with Free spare part.


Connection Information:
Address: Sanxing Industry Park,
Zhangjiagang City, Jiangsu Province
Phone:+86 13962462093
Fax: +86-512-55398012
Prod Model: RO-13
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Power: by Order
Material: S.S 304 or 316
Control: Siemens PLC
State: New
Condition: High
Capacity: 10t Per Hour
Zhangjiagang Beyond Technology Co., Ltd. Has more than 15 years experiences on beverage filling and packing machinery. We devote ourselves to the development, research and production of liquid food and beverage packing and filling industry and automatic blow molding machine in China.

For beverage machine, our Main products including:

The capacity of 2000-- 40000 BPH for hot filling (juice and tea filling) and MID-temp filling and aseptic cold filling lines.

The capacity of 2000-- 40000 BPH for mineral water and purified water producing line.

The capacity of 2000 -- 36000 BPH for carbonated beverage and cold filling producing line.

The capacity of 1000_8000BPH for vinegar and alcohol producing line. The capacity of 100 -- 2000 TBH for 3 gallon and 5 gallon barrel producing line.

The capacity of 2000--10000 BPH for milk producing line.

All kinds of water treatment equipment.

PET perform inject and blowing-stretching machine.

Plate and tube UHT device, and CIP system.

We carry a strict quality management system in accordance with CE and ISO9001 requirements. We have established a complete processing line including design and manufacture and sale and after sale service. Our products are sold well around the world.

We are proud to adhere to our company slogan "Engineering Excellence". Please be free to contact us for more information and we are ready for making business relations with you in the near further.
