| gensets details | Voltage | 400/230v |
| frequency | 50hz | |
| phase | 3phase 4wire | |
| P. F | 0.8(LAG) | |
| OUTPUT | 40KW | |
| Engine technical data | Engine Model | 4BTA3.9-GM47 |
| Number of Cylinders | 4 cylinders in line | |
| Cycle | 4 stroke | |
| Aspiration | Turbocharged and aftercooled | |
| Bore× Stroke | 102 x120 mm | |
| Displacement | 3.9 L | |
| Prime Power / speed | 47KW / 1500rpm | |
| Speed Governor | electrical | |
| Cooling System | By heat exchanger | |
| Fuel Consumption at 100% Load | 213 g/kw. h | |
| Starter Motor | DC24V, | |
| alternator technical data | Alternator Model | MP-H-40-4 |
| Prime power | 40KW | |
| Frequency/speed | 50HZ/1500rpm | |
| Exciter type | Brushless, Self-excited | |
| Power factor | 0.8 | |
| Insulation Grade | H | |
| Protection Grade | IP23 | |
| Phase / wire | 3 phase 4 wires | |
| control system |
Microcomputer digital control, and reliable work; Digital display of parameters of diesel engine, and integration of measuring and monitoring; Modularization of functional configuration, and ntegration of product structures; Resistance to vibration, humidity, salt mist and high/low temperature; Powerful ability to resist interference, convenient installation and use, and high performance-price ratio; Remote monitoring of running parameters; Automatic zero set of lubricating oil pressure Accumulation of running period of diesel engine |
|
| Prod Model: | CCFJ40J |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Engine Brand: | Cummins |
| Prime Power: | 40kw/50KVA |
| Standby Power: | 44kw |
| Frequency: | 50Hz 1500rmp or 60Hz 1800rmp |
| Cooling Method: | Water Cooling |
| Stroke: | Four Stroke |
| Installation Method: | Fixed |
| Type: | Micro-Computer Control Automatic Diesel Generator |
