Cummins Marine Diesel Generator Set 90kw
| Price: |
US $ 2000/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T |
Cummins DCEC marine generator
Cummins series marine diesel generator sets have features of compact structure, large power, low oil consumption, low discharge, low noise, reliable performances, and long services life. Its professional service networks are spread across the country and world, which can provide 24 hours after service and assure the supplying of accessories in time.
Features:
Gen-set can use for Marine gen-set, Marine emergency gen-set or Harbor gen-set.
We use the marine synchronouse Alternator with the brands of Stamford, Marathon and etc. Also can be supplied at the request of customers.
Parallel connection: Two and more normal marine generator sets can transfer loading without stoping, and can realize parallel.
Protection function: Thare are over-limit alarming for speed, oil pressure, cooling water temperature and oil temperature.
Can provide CCS, BV, ABS, DNV classification certificate.
| DCEC 50HZ marine generator |
| Shanghai monarch power engineering limited |
| Cummins mairne generator | Genset Model | MP-CCFJ40-Z-W | MP-CCFJ80-Z-W | MP-CCFJ100-Z-W | MP-CCFJ140-Z-W | MP-CCFJ180-Z-W |
| Cummins mairne generator | Prime Power | 40kW | 80kW | 100kW | 140kW | 180kW |
| Cummins mairne generator | Standby Power | 44kW | 88kW | 110kW | 154kW | 198kW |
| Cummins mairne generator | Voltage(v) | 400/230 | 400/230 | 400/230 | 400/230 | 400/230 |
| Cummins mairne generator | (Hz/ rpm) | 50/1500 | 50/1500 | 50/1500 | 50/1500 | 50/1500 |
| Cummins mairne generator | Diesel Engine Model | 4BTA3.9-GM47 | 6BT5.9-GM100 | 6BTA5.9-GM115 | 6CTA8.3-GM155 | 6LTAA8.9-GM200 |
| Cummins mairne generator | Alternator | Marathon, Standford | Marathon, Standford | Marathon, Standford, | Marathon, Standford | Marathon, Standford |
| Cummins mairne generator | Cylinder No. | 4L | 6L | 6L | 6L | 6L |
| Cummins mairne generator | Bore & Stroke (mm) | 102×120 | 102×120 | 102×120 | 114×135 | 114×135 |
| Cummins mairne generator | Comp. Ratio | 16.5:1 | 17.3:1 | 17.3:1 | 17.3:1 | 16.6:1 |
| Cummins mairne generator | Displacement (L) | 3.9 | 5.9 | 5.9 | 8.3 | 8.9 |
| Cummins mairne generator | Start Mode | 24DCV | 24DCV | 24DCV | 24DCV | 24DCV |
| Cummins mairne generator | Insulation Grade | H | H | H | H | H |
| Cummins mairne generator | Fuel Consumption Rate | 211g/kW.h | 217g/kW.h | 212g/kW.h | 209g/kW.h | 205g/kW.h |
| Cummins mairne generator | Lub Capacity (L) | 9 | 16.3 | 16.3 | 19 | 27.6 |
| Cummins mairne generator | Dimensions | 2100×810×1230 | 2380×830×1230 | 2380×830×1230 | 2500×830×1230 | 2500×830×1300 |
| Cummins mairne generator | (L×W×H) |
| Cummins mairne generator | Net Weight (Kg) | 1130 | 1360 | 1360 | 1380 | 1500 |
| Prod Model: |
90kw |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Basic Diesel Generator |
| Installation Method: |
Fixed |
| Stroke: |
Four Stroke |
| Cooling Method: |
Water Cooling |
| Output Type: |
AC Three Phase |
Shanghai Monarch Power Engineering Limited has already established very close relationships with Cummins, Deutz, Isuzu, Lovol, Iveco, Nissan, Toyota and other manufacturers. We can also provide you with the complete series of engines with the brands above. The engines are used for marine propulsion, marine generators, industrial generators, construction engines, vehicle engines, agriculture engines, etc.
We has already established cooperation relationships with customers all over the world, with an experienced and professional staff group, as well as senior engineers, technicians and salesmen. Now our company is known as a leading manufacturer in supplying of diesel generators (for both industrial use and marine use).
We can provide you with generators which are approved by China Classification Society CCS. Our marine generator can be approved by CCS, ABS, BV, DNV, GL, LR, GL, RS, etc. With steady quality, quick and professional service, our company gains the general recognition from users at home and abroad.
We are sincerely looking forward to establishing business relationships with you for our mutual benefit.
Products of Monarch Power Limited dealing with
1) Diesel engine: CUMMINS B, C, ISBe, ISDe, ISLe, L, ISF2.8/3.8 and DEUTZ BFM1015, FL413 & FL513, TBD234 and 226B for vehicle; CUMMINS B, C, KTA, N and DEUTZ TBD234, 226B for marine; CUMMINS B, C and DEUTZ FL413&FL513, FL912&913, TBD234 and 226B for genset; CUMMINS B, C, M11 and DEUTZ FL413&FL513, FL511, FL912&FL913, 226B, BF4M1013&BF6M1013, BF1015, TBD234 for industry.
2) Engine spare parts and machinery components: Genuine, OEM and aftermarket parts for the CUMMINS, DEUTZ, KOMATSU and some Japanese serial car. Genuine and Chinese-made machinery parts for the heavy mchine. Cummins Marine Engine Parts.
3) Generator set: CUMMINS diesel generator set for landuse and marine; CUMMINS natural gas and biogas generator set. DEUTZ diesel generator set
Monarch Power Limited welcome to customers from all around the world to visit and expect to build long and friendly business relations with you and your company in the near future!
