Cummins marine auxiliary engine KTA38 series KTA38-DM power range from 560kw-1100kw.

Cummins KTA38-DM marine engine complete with heat exchanger, sea water pump
Instrument panel etc. CCS BV marine class, IMO Tier2 emission.

Engine specification

1. Model KTA38-DM

2. Bore * Stroke 159mm * 159mm
3. cummins KTA38-DM Marine engine Cylinders V type 12 cylinder, Air-Intake,Turbocharged and Aftercooled
4. Displacement 38L
5. Cooling heat exchanger with sea water pump or salt water pump

6. exhaust type: water cooled exhaust manifold
7. Rotation Direction Counter-clockwise (Facing the flywheel)

8. Electric system: 24V

9. Fuel consumption :185L/Hour
10. Rated engine power : 560-1100kw
11. Rated engine speed: 1500rpm 1800 rpm
12. Peak Torque: 3956N. M /1300rpm
13. Dimension: 2500mm*1350mm *1963mm

14. Net weight: 4500kg
15. match with Stamford marathon Leroysomer alternator

Cummins KTA38 marine engine Model for selecting

Model SO NO. prime max power application marine class

power(kw)

KT38-M	SO60008	596/1800		marine propulsion	CCS/IMO
KTA38-D(M)	SO60067	664/1500		auxiliary power	CCS/IMO
KT38-D(M)	SO60116	560/1500		auxiliary power	CCS/IMO
KTA38-D(M)	SO60117	664/1500		auxiliary power	CCS/IMO
KT38-D(M)	SO60132	560/1500		auxiliary power	CCS/IMO
KTA38-M0	SO60135	671/1800		marine propulsion	CCS/IMO
KT38-M0	SO60137	543/1744	597/1800	marine propulsion	CCS
KTA38-M1	SO60155	746/1800		marine propulsion	CCS/IMO
KTA38-D(M)	SO60164	880/1500		auxiliary power	CCS/IMO
KT38-M	SO60170	582/1800		marine propulsion	CCS/IMO
KT38-D(M)	SO60173	679/1800		auxiliary power	CCS/IMO
KTA38-D(M)	SO60174	1007/1800		auxiliary power	CCS/IMO
KTA38-D(M)	SO60175	809/1800		auxiliary power	CCS/IMO
KT38-D(M)	SO60176	560/1500		auxiliary power	CCS/IMO
KTA38-D(M)	SO60177	664/1500		auxiliary power	CCS/IMO
KTA38-D(M)	SO60178	814/1500		auxiliary power	CCS/IMO
KTA38-D(M)	SO60179	880/1500		auxiliary power	CCS/IMO
KTA38-M2	SO60180	895/1800		marine propulsion	CCS/IMO
KT38-M	SO60186	407/1744	448/1800	marine propulsion	CCS
KTA38-D(M)	SO60232	664/1500		auxiliary power	BV Class
KTA38-D(M)	SO60236	880/1500		auxiliary power	BV Class
KTA38-M2	SO60240	895/1800		marine propulsion	BV Class
KTA38-M1	SO60243	746/1800	821/1858	marine propulsion	CCS
KT38-D(M)	SO60245	679/1800		auxiliary power	BV Class
KT38-D(M)	SO60246	560/1500		auxiliary power	BV Class
KT38-M	SO60266	440/2027	484/2100	marine propulsion	CCS
KTA38-M2	SO60270	895/1800	985/1858	marine propulsion	CCS
KT38-D(M)	SO60280	679/1800		auxiliary power	CCS/IMO
KTA38-M2	SO60285	895/1800		marine propulsion	BV Class
KTA38-M2	SO60287	407/1600	448/1652	marine propulsion	CCS
KT38-M	SO60288	350/1600	385/1652	marine propulsion	CCS
K38-DM	SO60289	746/1500	821/1500	auxiliary power	CCS/IMO TIRE2
K38-DM	SO60290	821/1800	903/1800	auxiliary power	CCS/IMO TIRE2
K38-DM	SO60291	880/1500	970/1500	auxiliary power	CCS/IMO TIRE2
K38-DM	SO60292	970/1800	1067/1800	auxiliary power	CCS/IMO TIRE2
K38-M	SO60293	1007/1900		marine propulsion	CCS/IMO TIRE2
K38-M	SO60294	895/1800		marine propulsion	CCS/IMO TIRE2
KTA38-D(M)	SO60296	1007/1800		auxiliary power	CCS/IMO
K38-M	SO60298	671/1600		marine propulsion	CCS/IMO TIRE2
K38-M	SO60300	1007/1900		marine propulsion	CCS/IMO TIRE2
K38-M	SO60301	970/1800	1067/1800	marine propulsion	CCS/IMO TIRE2
K38-M	SO60302	560/1600		marine propulsion	CCS/IMO TIRE2
K38-M	SO60303	596/1800		marine propulsion	CCS/IMO TIRE2
K38-M	SO60304	634/1800		marine propulsion	CCS/IMO TIRE2
K38-M	SO60305	746/1800		marine propulsion	CCS/IMO TIRE2
K38-M	SO60306	821/1800		marine propulsion	CCS/IMO TIRE2
K38-M	SO60307	821/1801		marine propulsion	CCS/IMO TIRE2
K38-M	SO60308	969/1800		marine propulsion	CCS/IMO TIRE2

If you interested in the cummins marine diesel engines, please free to contact us.

Prod Model:	KTA38-DM
Markets:	South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Emission:	Imotier1, Imo Tier2
Warranty:	18 Months
Delivery Time:	20 Days
Application:	Auxiliary
Marine Class:	CCS,BV, Dnv, Nk,Kr
Dimension:	2500mm1350mm 1963mm
Weight:	4350kg
Cylinders:	12
Engine Capacity:	38
