The engine ismanufactured by Dongfeng Cummins Engine Co., Ltd. And Chongqing Cummins Engine Co., Ltd. Cummins Inc., a global power leader, is a corporation of complementary business units that design, manufacture, distribute and service engines and related technologies. With the advantage of advanced, economical, powerful, reliable, durable technology, their products have been used in more than 160 countries.
We use the brushless alternator which is produced by the world famous Leroy Somer Electro-Technique (Fuzhou) Co., Ltd. LSA alternators are provided with a 2/3 winding pitch as standard, and are therefore perfectly suited to installations with distorting loads. It is compatible with engine drive systems, whether in regard to electrical power, torsional compatibility, coupling characteristics or dynamic operation in conjunction with the engine.
Detailed Prodcut Description
1. Engine: Cummins (Chinese)
2. Alternator: Leroy Somer, Stamford or Marathon
3. Rated Voltage: 50Hz: 400/230V 60Hz: 480/277V
4. Thrdd-phase voltage available: 480/277V, 440/254V, 220/127V, 207/120V
5. Power range: 20KW-1000KW(25KVA-1250KVA)
6. Rated Frequency: 50Hz/60Hz
7. Rated Speed: 1500RPM/1800RPM
8. Excitation way: Brushless Excitation
9. Inspiration method: Natural aspirated or Turbocharged
10. Cooling Method: Water-cooled
11. Governor Method: Electrical or Mechanical governor
12. Cylinder: 4L-12V
13. Phase: Three phase, four wires
14. Protection: IP21, IP22 or IP23
15. Insulation Class: H
16. AMF, ATS, Soundproof conopy and movable trailers for choices.
17. Standard: CE and ISO9001, ISO14000
18. Packing: Plastic or as per customers requirements
| GTL-Cummins Generator Sets |
| Genset model | Engine model | 50HZ | Fuel consumption | weight |
| 50HZ | 60HZ | Prime power | Stanby power | 1500r/p | |
| KVA | KVA | L/h | kgs |
| AC275 | AC315-T6 | MTA11-G2A | 250.0 | 275.0 | 45.4 | 3000 |
| AC350 | AC345-T6 | MTA11-G3 | 313.0 | 350.0 | 65 | 3220 |
| AC390 | / | NTA855-G2A | 356.3 | 391.9 | 76 | 3300 |
| AC390 | / | NTAA855-G7 | 375.0 | 412.5 | 83 | 3450 |
| AC450 | AC480-T6 | NTAA855-G7A | 400.0 | 450.0 | 79 | 3450 |
| AC500 | AC560-T6 | KTA19-G3 | 450.0 | 500.0 | 97 | 4300 |
| AC565 | AC625-T6 | KTA19-G4 | 500.0 | 565.0 | 107 | 4450 |
| AC630 | AC646-T6 | KTAA19-G5 | 525.0 | 631.0 | 126 | 4500 |
| AC688 | / | KTAA19-G6A | 625.0 | 688.0 | 206 | 4700 |
| AC825 | AC1000-T6 | KTA38-G2 | 750.0 | 825.0 | 167 | 6750 |
| AC1000 | / | KTA38-G2A | 910.0 | 1000.0 | 191 | 6950 |
| AC1100 | / | KTA38-G5 | 1000.0 | 1100.0 | 245 | 8300 |
| AC1375 | / | KTAA38-G9A | 1250.0 | 1375.0 | 243 | 8900 |
| AC28 | AC30-T6 | 4B3.9-G1 | 25.0 | 27.5 | 6.7 | 710 |
| AC28 | AC45-T6 | 4B3.9-G2 | 25.0 | 27.5 | 9.3 | 710 |
| AC40 | AC40-T6 | 4BT3.9-G1 | 37.5 | 41.0 | 10.7 | 770 |
| AC40 | AC40-T6 | 4BT3.9-G2 | 37.5 | 41.0 | 10.7 | 770 |
| AC55 | AC60-T6 | 4BTA3.9-G2 | 50.0 | 55.0 | 10.7 | 800 |
| AC110 | AC95-T6 | 6BT5.9-G1 | 100.0 | 110.0 | 20 | 1400 |
| AC110 | AC120-T6 | 6BT5.9-G2 | 100.0 | 110.0 , | 1400 | |
| AC138 | AC138-T6 | 6BTA5.9-G2 | 125.0 | 137.5 | 30 | 1480 |
| AC138 | AC155-T6 | 6BTAA5.9-G2 | 125.0 | 137.5 | 38.6 | 1530 |
| AC165 | AC180-T6 | 6CTA8.3-G2 | 150.0 | 165.0 | 40 | 1780 |
| AC205 | AC220-T6 | 6CTA8.3-G2 | 187.5 | 206.0 | 40 | 1880 |
| AC220 | AC250-T6 | 6CTAA8.3-G2 | 20.0 | 220.0 | 45 | 1950 |
| AC250 | AC295-T6 | 6LTAA8.9-G2 | 250.0 | 275.0 | 54 | 2150 |
Xiamen GTL Power System Co., Ltd., specializes in the professional manufacturing and development of generators since 2001, GTL has accumulated a rich experience in the production of diesel generator sets, GTL has widely cooperated with international and demestic well-know engines and alternator's manufactures, and developped diesel generator 5KVA~1250KVA; In addition, GTL has invested a lot in deleloping Soundproof type, weatherproof type diesel generator set; Trailer type, ON-vehicle type movable power station. All of the control panel, Automatic transfer switch, base fuel tanks, soundproof canopies, trailers, and parallel systerms are original, designed and manufactured in GTL factory. GTL can provide "customize" product based on the customer's request, therefore products can be involved in the field of greater use. GTL products are widely exported to worldwide. GTL focus on new product research, development and innovation and continuously strengthen technological innovation to improve product quality. Customer satisfaction of all people the same GTL commitment and the eternal pursuit.
