Technical Data
GROUP
Manufacturer: Powers city
Model: CS220
Frequency: 50Hz
Power
Standby Power: 176KW / 220KVA
Prime Power: 160KW / 200KVA
Open type
Dimension(L*W*H) mm: 2300 850 1400
Weight Kg: 1200
DIESEL ENGINE
Engine Manufacturer: Cummins
Model: 6CTAA8.3-G2
Cylinder Arrangement: 6 in line
Air Intake System: Turbo, Water /Air Cooling
Fuel System: PB/W type fuel pump
Displacement: 8.3L
Bore and Stroke: 114 135(mm)
Compression Ratio: 16.0: 1
Rated RPM: 1500rpm
Max. Standby Power at Rated RPM: 183KW/249HP
Frequency Regulation, Steady State: ≤1.5%
Exhaust Gas Flow: 34m³/min
Max Intake Restriction: 6.3kPa
Total Oil Capacity: 24L
Total Coolant Capacity: 28L
Alternator
Manufacturer: Stamford
Model: UCI 274G1
Connecting Type: 3 Phase and 4 Wires, "Y"
Protection Grade: IP23
Altitude: ≤1000m
Exciter Type: Brushless, self-exciting
Insulation Class: H/H
Telephone Influence Factor (TIF): <50
THF: <2%
Voltage Regulation, Steady State: ≤1%
Alternator Capacity: 230KVA
Alternator Efficiencies: 94.3%
Air Cooling Flow: 0.514m³/s
With full experience of manufacture and service, Powers City always supplies the product with high quality and competitive price in the international market. The power range of "Powers City" covers from 6kW/8kVA to 2, 000kW/2, 500kVA. Powers City has steady and long-term cooperation with world leading companies, such as famous engine manufacturer Cummins, Perkins, Deutz, Volvo etc., together with the world famous generator Stanford, Marathon, Leroy Somer.
