We can offer the Cummins 230kVA / 180KW marine diesel generator / genset.
It is installed on Cummins marine engine and Marathon alternator.
The Cummins 230kVA marine generator can be applied for fishing boat, Barge boat,
It can be used for maine main generator or marine emergency generator
Cooling mode can provide heat exchanger or radiator cooling.
Marine alternator can provide STAMFORD, MARATHON, Siemens, enclosure class can select IP23 or IP44.
It can provide CCS, BV, ABS, GL, LR, DNV and other specific classification certificate.
|
Type of Gen-set |
Cummins marine diesel generator |
|
Rated Capacity(KVA) |
230 |
|
Rated Power(kW) |
180 |
|
Type of Alternator |
MP-H-180-4 |
|
Type of Diesel Engine |
6LTAA8.9-GM200 |
|
Power of Diesel Engine(kW) |
200 |
|
Diesel Engine Cooling Mode |
Heat Exchanger or Radiator Cooling |
|
Rated Voltage(V) |
380 / 400 / 415 |
|
Rated Current(A) |
280 |
|
Rated Frequency(Hz) |
50HZ |
|
Power Factor(Lagging) |
0.8 |
|
Phase & Connection |
Three Phases & Three Wires, Y Connection |
|
Rated Speed(r/min) |
1500 |
|
Fuel Consumption(g/kW.h) |
≤225 |
|
Starting Mode |
Electric Starting \ Air Starting or Spring Energy-Saving Device Starting |
|
Weight of Gen-set(kg) |
1600 |
|
Overall Dimension (mm) |
2130x1200x1390 |
Shanghai Rekino Engine Equipment Co., Ltd. is engaging on exploring the engine customer all over the world. Our market will focus on marine engine, construction engine, industrial engine; Experically, Mining engine market will become a increasing market for our company in the future. Such as Cummins engine, Deutz engine, Caterpillar engine, including Yuchai engine and Weichai engine, etc.
Meanwhile, "Rekino engine" will enlarge on CNG, LNG, LPG engine in the comming year, appling for Green engine and clean energy fields.
On the other hand, "Rekino engine" will develop the High-value engine parts, as injection pump, Crankshaft, camshaft, Air compressor, turbocharger, etc.
"Rekino engine" will supply the individualized engine production for each client.
We are hoping to estabilish the long run business with each.
