Quick Details:
Condition: New
Place of origin: China(mainland)
Brand name: UIG
Model number: KDO, KDN, KDON, KLN, KZO, KZON SERIES
Production capacity: 50-2000 m3/hour
Power: 60-1000 KW
Voltage: 220V, 380V, 400V, 440V
Certification: ISO 9001: 2000
Warranty: 1 year
Life: 20 years with proper maintenance
After-sales service provided: Engineers available to service plants overseas
Key words: Air separation plants, nitrogen machine, liquid nitrogen plant, liquid nitrogen machine, oxygen machine, liquid oxygen plant
Usage: Industrial and medical (oxygen, liquid oxygen, nitrogen, liquid nitrogen)
UIG Air separation plants are designed for a vast range of capacities and products summarized below: FOR OXYGEN 99.7 %
Two compression methods:
1)Internal compression air separation plants:
Air-Compressed-Precooling-Purifier-Rectification-heart exchanger (low pressure liquid)-Liquid oxygen pump(pressurized liquid oxygen)-oxygen vaporizer - oxygen cylinders
2)External compression air separation plants:
Air-Compressed-Precooling-Purifier-Rectification-heart exchanger (low pressure gas)-oxygen storage-oxygen compressor(pressurized oxygen)-oxygen cylinders
|
Model contents |
KLN-
8Y |
KLN-
30Y |
KDON-
100Y/100Y |
KDON-
200/200Y |
KDON-
300Y/300Y |
KDON-
500Y/500Y |
KDON-
800Y/800Y |
KDON-
1000Y1000Y |
|
Lo2 flow |
L/h |
-- |
-- |
100 |
200 |
300 |
500 |
800 |
1000 |
|
Lo2 purity |
%(o2) |
-- |
-- |
99.6 |
99.6 |
99.6 |
99.6 |
99.6 |
99.6 |
|
Lox pressure |
Mpa |
-- |
-- |
~0.03 |
~0.03 |
~0.25 |
~0.25 |
~0.25 |
~0.25 |
|
LN2 flow |
L/h |
8L/h |
30L/h |
Or 100 |
Or 200 |
Or 300 |
500 |
Or 800 |
1000 |
|
LN2 purity |
%(N2) |
99.9 |
99.9 |
99.999 |
99.999 |
99.999 |
99.999 |
99.999 |
99.999 |
|
LN2 pressure |
Mpa |
Ordinary pressure |
Ordinary
pressure |
~0.025 |
~0.025 |
~0.4 |
~0.4 |
~0.4 |
~0.4 |
|
Start-up time |
h |
1 |
2 |
5-8 |
8-12 |
-16 |
-22 |
-20 |
-26 |
|
Operating period |
year |
-- |
-- |
≥2 |
≥2 |
≥2 |
≥2 |
≥2 |
≥2 |
Hangzhou Union Industrial Gas-equipment Co., Ltd. Are a technology enterprise specialized in R&D, design and manufacture of various air separators and cryogenic application equipments. Our company always insists on taking the technology as the motility, emphasizing technique and products innovation, cooperating with many scientific and research institutes, academic schools which are in the same industry range with us. On the basis of integration into advanced design concept and strict management procedure and the outstanding production technique and give the enthusiastic service support. Decisive adoption of new processes, new technology, the R&D and manufacturing capability of the company is enhanced and the development is oriented to the Saving Energy variety and perfection of the products.
The products of the company cover the fields of metallurgy, petrochemical industry, electronics, machinery, construction material, Medicine, New materials which have been well received all over the country and also been supplied to many Asian and African countries(Russia, Kazakhstan, Tajikistan, India, Bangladesh, Thailand, Philippines, North Korea, Mongolia, Equatorial Guinea, Botswana, Zambia, Angola, Tanzania). The main products are: the medium and small size oxygen nitrogen plants, liquid oxygen and liquid nitrogen plants, oxygen and nitrogen liquefaction plants, high purity nitrogen generators, molecular sieve pressure swing adsorption plants and PSA (VPSA) oxygen (nitrogen) plants.
In addition to provide high-quality products, our company also undertakes technical consulting, engineering design, equipment installation, technical training and other services, and implementation of the turn-key project. Sincerely welcome your contact and visit to the company.
