| Model No | Ozone output(g/hr) | Power(W) | Voltage(V) | Size(cm) | Weight(kg) | Oxygen generator |
| YT-015 | 5g/h | 660W | 220-110V/50-60HZ | 55*44*73cm | 40kg | In-built |
| YT-015 | 10g/h | 680W | 220-110V/50-60HZ | 55*44*73cm | 43kg |
| YT-016 | 15g/h | 780W | 220-110V/50-60HZ | 55*44*88cm | 50.8kg |
| YT-016 | 20g/h | 850W | 220-110V/50-60HZ | 55*44*88cm | 50.8kg |
| YT-016 | 30g/h | 950W | 220-110V/50-60HZ | 55*44*88cm | 50.8kg |
| YT-016 | 40g/h | 110W | 220-110V/50-60HZ | 55*44*103cm | 52kg |
| YT-017 | 50g/h | 1200W | 220-110V/50-60HZ | 55*44*103cm | 52kg |
| YT-017 | 60g/h | 1300W | 220-110V/50-60HZ | 55*44*103cm | 75.5kg |
| YT-017 | 80g/h | 1750W | 220-110V/50-60HZ | 55*44*138cm | 86.5kg |
| YT-018 | 100g/h | 2650W | 220-110V/50-60HZ | 55*44*143cm | 106.5kg |
Features:
1. Carbon steel sprayed with plastic housing;
2. Built-in PSA high purity twelve tower oxygen sieve;
3. Built-in patent of product -Air cooling Ceramic ozone tube with high frequency electric board, high
ozone concentration and stable ozone capacity, long life time;
4. Built-in Oil-free air compressor;
5. Built-in Air dryer and filters. To supply cool, dry, clean air source for air compressor and PSA
oxygen concentrator;
6. Manual control, easy operation and maintenance.
Applications:
1. Aquactulture,Aquarium,Fish farming Water treatment
2. Cooling towers water treatment
3. Swimming pools Water treatment
4. Sewage water treatment
5. Water Disinfection& sterilization
Control panel:
Voltmeter, Amp meter, Timer, Ozone Amp meter, Main switch, Power supply switch, Emergency stop,
working light, Power light, Alarm
Control protection:
Over current protection
Electric leakage protection
Short circuit protection
Over heat of air compressor protection
Time delay system protection
Learn more details informations about this product, please click the link below:
http://www.alibaba.com/product-detail/waste-water-treatment-ozone-generator-ozone_60233329804.html?spm=a2700.7724838.30.319.fbxF71
Contact us:
Minya Tang
Tel / : +86-13022028529
Guangzhou Jiahuan Appliance Technology Co.,Ltd
Guangzhou Jiahuan Application Techology Co. Ltd has lined in ozone generator for over 10 years, with high quality and reasonable price for our dear customers. And we have a very good reputation on the markets. We are manufacture of the ozone generator varied from 5g/hr to 2kg/hr ozone with oxygen feeding or air feeding, 3LPM to 300LPM PSA oxygen generator/concertration, car air purifier with ozonizer and ionizer, ozonated water machine, erc.
