412.5kVA Silent Generator Specification:
Prime Power: 300kW/375kVA;
Standby Power: 330kW/412.5kVA
Engine Brand: Cummins, Perkins, MTU, etc.
Alternator Brand: Faraday, Engga, Siemens, etc. (100% copper wire).
Rated Voltage: 220V/380V, 230V/400V, 240V/480V, 254V/440V etc.
Frequency: 50Hz/60 Hz.
Rated Speed: 1500rpm/1800rpm.
Rated Power Range: 22kW~2000kW / 27.5kVA~2500kVA.
Automatic Controller: Deep Sea or Hassan.
Noise Level: 65-80dB( at 7 meters distance).
Fuel Tank Capacity: 8 hours(standard).
Cooling Method: Water Cooling.
Stroke: Four Stroke.
Installation Method: Fixed
Silent Generator Set Specification:
Silent/Soundproof/Containerized Diesel generator set power range 22kW~2000kW / 27.5kVA~2500kVA
General specifications of silent generator:
Modular design
Anti-corrosion powder coated
Insulated with acoustic foam lining
Central lifting ring, exhaust pipe can be removed which is easy for ransportation
Lockable doors with key
Protective mesh for rotating parts
Exterior emergency stop push button
Thermally insulated engine exhaust system
Doors fitted on each side
Panel observing window
Access to radiator filling or cap
20', 30' or 40' container canopy is optional
Color is optional
1. Rated voltage: 400V/230V, 380V/220V, 240V/120V, 220V/110V
2. Line way: 3 phases & 4 lines
3. Frequency: 50Hz/60Hz
4. Power factor: 0.8 (lagging)
5. Frequency down (%): ≤ 0.5
6. Steady voltage windage (%): ≤ ± 1
7. Instantanous frequency windage (%): (rated power ) +10~ -7
8. Frequency recovering time (s): ≤ 3
9. Instantanous voltage windage (%): +20~ -15
10. Voltage recovering time (S): ≤ 4
11. Wave form distortion (%): ≤ 5
Guangdong Binshi Power Technology Co., Ltd is one of the leading manufacturers of diesel and gas generator sets (generator, genset, diesel generator, power generator, silent generator, generating set, power generation). With years' professional experience in generator set design, manufacturing, sale and service, BS Power has won good reputation both at home and abroad.
BS Power has built a number of production bases and service centers across the country. Among them, the South China production base and after-sales service center which is located in Dongguan-the famous manufacturing city in the world, covering an area of 8, 000 square meters, owns more than 100 employees, in which 58 percent is engineering technicians, and has numbers of senior engineers. BS Power is people-oriented, creating the best technical management, marketing and planning talents. With abundant resources and innovative research capabilities, BS Power has established a research and development center with famous domestic universities.
In order to improve BS Power's production and technology capability. The second production base, which is located in Hubei Province with the total investment of 7, 000 million yuan, covering an area of 35, 000 square meters, has been put into production.
BS Power has established long-term close partnership with the world famous generator manufactures, such as Cummins in USA, Perkins in UK, MTU and Deutz in Germany, Doosan in Korea, and the genset is equipped with the famous alternator manufactures, like Marathon (USA), Leroy-somer(France) and Engga(UK). Meanwhile, BS Power has achieved ISO9001: 2008 Quality Certification System and ISO14001: 2004 Environmental Management System.
BS Power sincerely wishes to cooperate with distributors of gensets worldwide to expand its high-quality products in your market to reach the win-win goal in the future. Information about BS Power(manufacturer), products will be offered on your request.
