Home Generator Products Citic Shuguang Brand Steam Turbine Generator for Sale

Citic Shuguang Brand Steam Turbine Generator for Sale

Citic Shuguang Brand Steam Turbine Generator for Sale
Price: US $ 500000/Set
Trade Terms: FOB,CFR,CIF
Min Order: 1/Set
Pay Type: L/C,T/T,D/P,Paypal,Money Gram
CITIC SHUGUANG Steam Turbine Generator for Sale

Pre-design Reference
Extraction Condensing Steam Turbine Generator Specification
Model Rated power   KWInlet Steam Parameter Exhaust Pressure MPa(a) Speed(r/min)
Pressure(MPa)Temperature°C
C110001.8-3.34320-4350.0085600/3000
C315001.8-4.35320-5350.0085600/3000
C4.530002.3-8.89390-5350.0075600/3000
C645002.3-8.89390-5350.0073000
C7.560002.3-8.89390-5350.0073000
C975002.3-8.89390-5350.0073000
C1290002.3-8.89390-5350.0063000
C15120002.3-8.89390-5350.0063000
C18150002.3-8.89390-5350.0063000
C20180003.5-8.89430-5350.0063000
C25200003.5-8.89430-5350.00473000
C30300003.5-8.89430-5350.00473000
C40400008.895350.00473000
C50500008.895350.00473000

Pre-design Reference
Condensing Steam Turbine Generator Specification
Model Rated output  KWInlet Steam Parameter Exhaust Pressure MPa(a) Rated Speed (r/min)
Pressure MPa(a)Temperature°C
N110000.45-3.34180-4350.00945600/3000
N330001.57-4.35390-5350.0075600/3000
N4.545001.57-8.89390-5350.0073000
N660001.57-8.89390-5350.0073000
N7.575001.57-8.89390-5350.0073000
N990001.57-8.89390-5350.0073000
N12120002.3-8.89390-5350.0063000
N15150002.3-8.89390-5350.0063000
N18180002.3-8.89390-5350.0063000
N20200002.3-8.89390-5350.0063000
N25250002.3-8.89390-5350.00473000
N30300002.3-8.89390-5350.00473000
N40400003.5-8.89430-5350.00473000
N50500003.5-8.89430-5350.00473000

Pre-design Reference
Back Pressure Steam Turbine Generator Specification
Model Rated power(KW)Inlet Steam Parameter Exhaust Pressure MPa(a) Rated Speed (r/min)
Pressure(MPa)Temperature°C
B1-31000-30000.9-4.9 260-4350.1-1.6 3000
B330001.2-8.89350-5350.29-2.05600/3000
B4.5 45001.2-8.89350-5350.29-2.03000
B660001.2-8.89350-5350.29-2.03000
B7.575001.2-8.89350-5350.29-2.03000
B990001.2-8.89350-5350.29-4.03000
B12120001.2-8.89350-5350.29-4.03000
B15150001.2-8.89350-5350.29-4.03000
B18180001.2-8.89350-5350.29-4.03000
B20200002.3-8.89390-5350.29-4.03000
B25250002.3-8.89390-5350.29-4.03000
B30300002.3-8.89390-5350.29-4.03000
B40400003.5-8.89430-5350.29-4.03000
B50500003.5-8.89430-5350.29-4.03000

Application:
1) Cogeneration: high thermal efficiency, widely used in brewing, sugar refining, pharmaceutical, textile, printing and dyeing, chemical fertilizer, chemical, regional heating and other industries.
2) Waste heat and energy utilization: steel blast furnace gas, metallurgy sintering waste heat, waste heat at the cement kiln head and inlet, glass kiln waste heat, chemical kiln waste heat, coking waste heat, gas turbine waste heat and other waste heat and waste energy.
3) Biomass power generation: wood chip, straw, leaves, husks, furfural residue, bagasse, palm shell and ordinary trash, etc. can be used for power generation.
4) Other fields: low concentration mine gas, coal slime, saturated steam, etc.
5) Industrial drives:  energy-saving substitute for electric motor. Widely applied in the petrochemical industry, directly driven air blowers, compressors, and other highly energy-intensive equipment.

Advantage:
1) A steam turbine and generator research & development center with a history over 40 years.
2) All the parts including shafts, blades, wheels and castings are manufactured in house to ensure the quality and guarantee the lead time.
3) Turnkey service, including project design, production, construction, installation, and adjustment, is provided to help customers successfully accomplish projects with least concentration.
4) Low steam consumption rate, high efficiency, long operating life.
5) Strong overload capacity, easy to operate, safety guaranteed.
6) Three dimensional designed by CAD, CAE, CAM.
7) Manufacturing customized products.

Service:
1) 18 months warranty after the delivery
2) Arriving at your construction site within 7 days after being notified.
3) After-sales service beyond warranty period to ensure the long-term safe operation of the unit.
4) Regular return visit to our clients to follow up with all the service.
5) All the spare parts will be reserved in stock to meet the instant demands of our customers.

Customers we have served
1. Thailand Beststair Company 6 sets of 400kw Biogas Generator Units
2. Thailand CP Group 3 sets of 450kw Biogas Generator Units
3. Thailand Sakon Nakhon Biogas Power Plant 3 sets of 400kw Biogas Generator Units
4. Philippines Lucky PPH International 8 sets of 450 kw Biogas Generator Units
5. Philippines MR VALE PALILIO 10 sets of 400kw Biogas Generator Units
6. Italian Sitech Italia S. R. L. 5 sets of 400kw Biogas Generator Units 12 sets of 400kw Biogas Generator Units
More and more customers are using our steam turbine at present.

Factory;
Shanghai Brilliance General Equipment Co., Ltd. is the foreign trade subsidiary of CITIC HIC Luoyang Generating Equipment Co., Ltd.. CITIC HIC Luoyang Generating Equipment Co., Ltd. was established in 1971 with strong research and design capabilities. Specializing in manufacturing the whole set steam turbine and generator set, we have passed the ISO 9001 certification. Now , we specialize in the researching and manufacturing power generation steam turbine and dragging-type steam turbine ranges 1-60 MW,  including Condensing , Back Pressure , Extraction Condensing types, serving for many different industries like Textile, Chemical, Paper making, Food & Sugar, ects. The company mainly engages in the development of various types of waste heat energy project. We can provide turnkey service including project design, production, construction, installation, and adjustment, which helps our customers accomplish the whole project with least time and concentration. We are dedicated to serving our customers with our best effort!

Prod Model: SA150202005
Markets: South America,Southeast Asia,Africa,Mid East
Product: Citic Shuguang Steam Turbine Generator for Sale
Rated Power: 1000 Kw - 60000 Kw
Steam Flow Rate: 9 - 317 T/H
Inlet Steam Pressure: 0.9 MPa - 8.89 MPa
Inlet Steam Temperature: 260-535 Degrees Celsius
Exhaust Pressure (a): 0.0047 MPa- 0.98 MPa
Rated Speed: 5600/3000 (R/Min)
Frequency Of Motor: 50Hz, 60Hz, or on Request
Certificate: ISO
Design: Customized
Power: 1-60MW
Shanghai Brilliance General Equipment Co., Ltd. is the foreign trade subsidiary of CITIC HIC Luoyang Generating Equipment Co., Ltd...CITIC HIC Luoyang Generating Equipment Co., Ltd. Was established in 1971 with strong research and design capabilities as well as advanced machining center and experimental equipment. Specializing in manufacturing the whole set steam turbine and generator set, we have passed the ISO 9001 certification.

There are over 760 employees, including 151 technical engineers and 22 technicians combined with over 40 foreign trade staffs in Shanghai subsidiary. There are 500 units main processing equipment, with 60 precision equipments; More than 20 CNC equipments; And 4 blade machining centers. All of these guarantee our quality-control capability in every production process.

For over 40 years, our steam turbines have been sold all over the country, and exported to Asia, Africa, South America, and Eastern Europe.

Now, we specialize in the researching and manufacturing power generation steam turbine and dragging-type steam turbine ranges 1-60 MW, including Condensing, Back Pressure, Extraction Condensing types, serving for many different industries like Textile, Chemical, Paper making, Food & Sugar, ects. The company mainly engages in the development of various types of waste heat energy project.

We can provide turnkey service including project design, production, construction, installation, and adjustment, which helps our customers accomplish the whole project with least time and concentration. 18months warranty is guaranteed with in-time after service.

We are dedicated to serving our customers with our best effort!
