Our Advantages
1. High pressure pipes for diesel input-outlet
2. Stronger heavy duty rubber anti-vibration mountings
3. All base fuel tank Baking paint
4. All canopy powder coating (Powder type - 3 years durable, longer service life and less color fading)
5. Maintenance free battery and high quality battery charger
6. High standard wiring and brands (Chint/Delixi) relays, indicators, fuse breaker, meters etc.
7. Non-return Valve equipped
8. Turbo charger protection, moving parts protected and other CE standards (depends on required)
9. ONE Hour Testing for all genset (0%-25%-50%-75%-100%-110% loading)
10. Make sure the Fastest Delivery Time
11. Reliable Quality and Aftersale Services as committed
12. Excellent Quality Control and Pre-shipment Inspection
(All base frame, fuel tank, canopy, ATS cabinets etc are produced in Tangpower factory zone to avoid any out-off-controlled quality problems.
Engine feature
→Diesel, heavy-duty, four stroke, water cooled and direct injection fuel system
→24V D. C starter and charger alternator
→Industrial capacity exhaust silencer supplied loose with flexible section
And mating connections
→ Set mounted tropical duty radiator
→Engine driven cooling fan with protection guard
→Steel wire braided fuel lines, vent and rain fittings
→Set mounted acid battery installed with leads and terminals
Alternator feature
Brushless self excited, single bearing, 4 poles
Class H insulation
IP23 protection standard
Self-exciting and self-regulating
Automatic voltage regulator (AVR)
Warranty policy
Guarantee for one year or 1000 hours whichever reach first from ex-factory date. During the guarantee period, Tang Power will provide the free easy-damageable spare parts of diesel engine caused by our quality of production or raw material. After expiration, Tang Power provides cost spare parts maintenance of gensets.
Genset ' s Data |
Genset Model |
GDW10 |
Prime Power (kw/kva ) |
8KW/10KVA
|
Standby Power(kw /kva ) |
8.8/11 |
Rated Voltage |
400/230V (Adjustable) |
Frequency |
50Hz |
Radiator |
50°C suitable for tropical weather |
Charge Alternator |
24V |
Dimension(L*W*H) (mm) |
1270*720*1120 (Open genset ) |
Net Weight (kg) |
350KG |
Base Feul Tank Capacity |
Enough for Genset 8-10 Hours Continuous Running |
Diesel Engine Data |
Brand |
Yangdong |
Model |
YD380D |
Governor Type |
L |
Rotating Speed |
1500 r.p.m |
Engine Cooling Method |
Water-cooled |
Cylinder Nos. |
4 |
Fuel consumption |
2.4L/h @100% full load |
Alternator Data |
Brand |
Godlike/Leroy Somer/ Stamford/ Mecc alte |
Model |
JDG164C |
Power Factor(COS Phi) |
0.8 |
Excite Type |
Brushless SHUNT |
Connecting Type |
3 Phase & 4 Wires |
Insulation Degree |
H |
Enclosure Degree |
IP23 |
AVR voltage regulation rate |
≤±0.5% |
