ChangChai Single Cylinder Diesel Genset(2kw to 20kw)
| Price: |
Negotiable |
| Min Order: |
1 |
Powered by Changchai series engine
The engine is single cylinder and water cooled.
Rate power: 3kw to 20kw
Optional:
Soundproof canopy type,
| Diesel Engine | Sets Model | GF1-3 | GF1-5 | GF1-8 | GF1-10 | GF1-12 | GF1-15 | GF1-20 |
| Power | 3kw | 5kw | 8kw | 10kw | 12kw | 15kw | 20kw |
| Model | S175 | S195M | S1100M | S1110M | S1115M | L24M | L32M |
| Starting System | MANUAL/ELECTRIC START |
| Fuel comsumption (gl/KW.h) | 270 | 250 | 250 | 250 | 250 | 240 | 240 |
| Type | HORIZONTAL,SINGLE-CYLINDER,FOUR-STEOKE,WATER-COOLED |
| Cooling Type | CLOSED CIRCULATING COOLING(CONDENSER) |
| Rated Speed | 1500/1800 |
| Alternator | Model | STC-3 | STC-5 | STC-8 | STC-10 | STC-12 | STC-15 | STC-20 |
| (ST-3) | (ST-5) | (ST-8) | (ST-10) | (ST-12) | (ST-15) | (ST-20) |
| Rated Freq.(Hz) | 50/60 |
| Rated Voltage (V) | 400/230 |
| Rated Current (A) | 5.4/12 | 9/21.8 | 14.4/34.8 | 18/43.5 | 21.6/52.2 | 27.1/65.3 | 36.1/87 |
| Rated Output (kW) | 3 | 5 | 8 | 10 | 12 | 15 | 20 |
| Power Factor | 0.8LAG(1.0) |
| Type | Brushless excitation,3PHASE(SINGLE-PHASE) |
| Dimensions(cm) | 105*50*75 | 132*65*86 | 132*65*86 | 132*65*86 | 132*65*86 | 143*75*90 | 143*75*90 |
| Net Weight(kg) | 170 | 320 | 350 | 360 | 380 | 410 | 420 |
| Specification given herein are subject to change without notice |
| Prod Model: |
SINGLE CYLINDER SERIES |
Established in 2000, FUAN ZONGCHI MOTOR CO., LTED is a profesional power generation equipment manufacturer, mainly produce generator and generating set.
Manufactory covers 20, 000 square meters, 12, 000 square meters are standard workshop, we have more than 160 staff, and 10 of them are technical personnels.
As a high-tech enterprise, we place great emphasis on quality, We have more than 100 series equipments to support and test our products, such as CAD system, CNC machining equipments, VPI equipment, auto testing system and auto painting lines.
At the same time, we have achieved accreditation to ISO9001: 2000 Systems certificates and boast a number of product certificates, including CE, CCS, CCC and others.
'Zongchi' brand diesel gen-sets have passed the strict technical demonstration. We have a good relationship with CUMMINS, DEUTZ, PERKINS (LOVOL), WEICHAI and chinese famous engine manufacturers. Together with the world famous generator STAMFORD, MARATHON and LEROY SOMER, or our TFW series brushless generator, It uses the lastest intelligent control technical.
Our annual turnover is up to 8 million dollars, with the capacity of 12, 000 sets per years, Our products are exported to more than 30 countries and regions, mainly in Europe, South America, and Middle East.
We warmly welcome every customer to cooperate with us on the basis of mutual benefit, hope to be your faithful friend and best partner.
