Home Generator Products CE & ISO Standard Top Quality 300 Kw Natural Gas Generator Set

CE & ISO Standard Top Quality 300 Kw Natural Gas Generator Set

CE & ISO Standard Top Quality 300 Kw Natural Gas Generator Set
Price: US $ 56800/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T

Natural gas---its main component is CH4,which takes 90% of the whole content. The displacement of NOX, CHM and Co from burning are much lower the state standards and without dust pollution; thermal efficiency of conversion is 65%, which is same to the LPG and higher than Coal; Calculated on the same calorific value, the price of natural gas is lower than the price of coal and petroleum. Natural gas is used by civil use, generation, industrial chemicals and industrial fuel etc. it's a good substitute of coal and petroleum. It can take instead of civil coal gas; it can be used as nitrogenous fertilizer instead of coal and petroleum; it can be used as ethylene instead of naphtha; it can be used as the car engine fuel instead of petroleum.


Shandong Lvhuan Power Equipment Co.,Ltd is a pioneer and practitioner in green energy and renewable resources.

Ignition system:We adopt ignition system of magneto which produced by American ALTRONIC company,including:magneto,high-tension coil,sparking plug.
Starting system: DC24V electric motor,12v190 adopt ST710 of direct-current.
Pressure charging system:Pulse Mixed-flow  supercharger, compression  ration is  1:8,meet engine's  requirement   for gas-flow rate.
Speed regulating system:EGS gas controller of American WOODWARD Company.
scope of application:Biogas generator set is widely used in the many area where can generate biogas,like rubbish landfill,livestock excrement disposal,industrial organism disposal.


Requirements for natural gas:
Within 1m from pressure regulating value of gas intake;
The ratio of CH4 in natural gas 70%;
Pressure of natural gas:80-200 kpa, rate of pressure change <1 kpa/min;
H2S<20mg/nm3;
Moisture content <40 g/Nm3;
Impurity particle size <5µm, impurity content <30 mg/Nm3

SHANDONG LVHUAN POWER EQUIPMENT CO., LTD.
Address: High-Tech Industries Development Zone Jinan City, Shandong,China
 Website: www.lvhuandongli.com/en


Parameter of Natural Gas Generator Set
Model Number (Engine Type) LHNG300
Brand Name LVHUAN
Prime Power/Standby Power 240KW/300KW
Rated Speed 1000/1200RPM
Rated Frequency 50/60Hz
Rated Voltage 400V/230V
Phase AC 3-Phase, 4 wire
Voltage Stability ≤±2%
Voltage transient ≤±10%
Voltage Stable time ≤1s
Heat consumption ≤11mj/kw.h
Lubricant consumption ≤1.0g/kw.h
Engine Capacity 32 L
Cylinder Number 6
Cylinder Bore 190mm
Stroke 210mm
Starting System DC 24V electric motor
Cooling method water cooler
Lubricant method Passive and flying lubricant
Isolation class H
Protection IP23
Alternator Siemens
Power Factor 0.8 lagging
Exciting method brushless
Colour your choice
Certificates ISO 9001:2008, CE
Warranty 1 year or 1000 running hours arrives first
Type Open
Control system Automatic alarm system
Size 5300x1970x2170mm
Weight 8200kg
Prod Model: LHNG300
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Exciting Method: Brushless
Cooling Mode: Circulating Water Cooling
Gas Mixing Type: Outside
Intake Mode: Natural Intake
Gas Pressure: 3-20 Kpa
Sparking Mode: Sparking Plug
Overhaul Time: >30000h
Gas Source: Natural Gas
Shandong Lvhuan Power Equipment Co., Ltd. is a manufacturer which specially produces internal-combustion gas engine generator sets and gas engines, with registered capital of more than RMB10 million, annual turnover of RMB100 million, over 200 staff, beautiful scenery and convenient transportation. Our factory mainly specializes in the design, research, production, sale, installation and technical service of gas generator sets and diesel generator sets. Our company has strong specialty, powerful technical force, a complete production plant, advanced processing technology, mature inspection method and a strict test system.

Our products include 105, 135 and 190 series base engines. The output power ranges from 10kw to 500kw. The gensets can be used for biogas, natural gas, oil associated gas, coal mine gas and mash gas produced by burying rubbish and sewage disposal.

We manage our company by ISO9001 system strictly. Gas engines and alternators are environment-friendly products.

Our philosophy is "Only pay attention to supplying stronger power to you". More importantly, combining with our continuous technological innovation and hard work, we believe that you will choose our company and keep a long-term business relationship with us!
