Home Generator Products CE & ISO Standard Green Power Water Cooling 300kw Biogas Generator

CE & ISO Standard Green Power Water Cooling 300kw Biogas Generator

CE & ISO Standard Green Power Water Cooling 300kw Biogas Generator
Price: US $ 60136/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T

1. Company Introduction
· Since 2008
· Factory area over 40000m2
· Starff over 260 employees
· All kinds of gas generator set
2. Advantage
· 10-1000kW natural gas generator sets
· manufacturer for over eight years
· With CE and ISO certificates
· one year warranty
· Easy Start & Auto start
· Perfect after-sales service
3.Parameters of biomass gas generator

Model Number (Engine Type)LHBG300
Brand NameLVHUAN
Prime Power/Standby Power240KW/300KW
Rated Speed1000/1200RPM
Rated Frequency50/60Hz
Rated Voltage400V/230V
PhaseAC 3-Phase, 4 wire
Voltage Stability≤±2%
Voltage transient≤±10%
Voltage Stable time≤1s
Heat consumption≤11mj/kw.h
Lubricant consumption≤1.0g/kw.h
Engine Capacity32 L
Cylinder Number6
Cylinder Bore190mm
Stroke210mm
Starting SystemDC 24V electric motor
Cooling methodwater cooler
Lubricant methodPassive and flying lubricant
Isolation classH
ProtectionIP23
AlternatorSiemens
Power Factor0.8 lagging
Exciting methodbrushless
Colouryour choice
CertificatesISO 9001:2008, CE
Warranty1 year or 1000 running hours which arrives first
TypeOpen
4.Gas Requirements For Biomass Gas Genset
 Within 1m to the intake valve of gas generator set
· Gas temperature ≤ 40ºC                                                                                                      · Pressure 3-20kpa, pressure changing rate ≤ 1kpa/min
· H2S ≤ 200mg/Nm3
· NH3 ≤ 20mg/Nm3
· Tar content≤20mg/Nm3
· CH4 content ≥40%, changing rate ≤ 2%/min
· Impurity particle size ≤ 5μm, impurity content ≤ 30mg/Nm3
· Moisture content ≤ 40g/Nm3
· Heat value≥4.2MJ/nm3
5.Pictures6.Certificates
7. Service

1.pre-sale service:
(1)We will send our engineer to prospect the site of power station free to charge.

(2)According to the situation of site we can supply you many drawings:like power station floor plan,
engineering flow sheet of circle cooling system,genset installation,genset foundation,electrical connection and some other techincal support etc.

2.Sale service:
(1)we will send our engineer to the site to guide you the installation of generator set, subsystem and relative equipment.

(2)We will debug the generator set till it can generate power successfully.

(3)We will also supply a technical training to the operators.Orcan send your staff to our company.We can train you till you can operate the generator set.

3.After-sale service:
(1)Our every engineers are in charge of different area,we will response periodically and support you
technical service free of charge,

(2)For the quality problem, we will service for you free of charge during the guarantee period.

(3)One year guarantee period and lifetime service.

(4)we solve quality problem in time when genset doesn't work,We insure to help our clients to gain the biggest economic profit.

8.FAQ:
1.How to choose the right model?
A: It depends on real output power, Voltage, Frequency and gas type.
2.What is the oil consumption and capacity per hour?
A: 1.0-1.63g of lubricant oil consumption per hour. 1.0 Cubic meter gas can produce 1.5-3.0kw/h power. The capacity depends on gas energy. E.g 1.0 Cubic meter natural gas produce about 3.0kw/h
3.What is the overhaul?
  A: About 30000 working hours. A week is enough to finish.
4. What is the warranty?
    A: 1 year. Inside this 1 year, we offer all spare parts free of charge. After this period, spare      parts are not free. But, a set of spare parts will be shipped together with machine free.
5. How is the service?
A: We offer installation,repair and maintain service abroad. And online guide service if needed anytime. Our before-sale, in-sale and after-sale service are all trustable, you can name it.
Prod Model: LHBG300
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Rated Power: 400/230V
Frequency: 50/60Hz
Speed: 1500rpm
Gas Pressure: 3-20 Kpa
Cooling Mode: Circulating Water Cooling
Type: Open or Closed
Gas Source: Biogas
Shandong Lvhuan Power Equipment Co., Ltd. is a manufacturer which specially produces internal-combustion gas engine generator sets and gas engines, with registered capital of more than RMB10 million, annual turnover of RMB100 million, over 200 staff, beautiful scenery and convenient transportation. Our factory mainly specializes in the design, research, production, sale, installation and technical service of gas generator sets and diesel generator sets. Our company has strong specialty, powerful technical force, a complete production plant, advanced processing technology, mature inspection method and a strict test system.

Our products include 105, 135 and 190 series base engines. The output power ranges from 10kw to 500kw. The gensets can be used for biogas, natural gas, oil associated gas, coal mine gas and mash gas produced by burying rubbish and sewage disposal.

We manage our company by ISO9001 system strictly. Gas engines and alternators are environment-friendly products.

Our philosophy is "Only pay attention to supplying stronger power to you". More importantly, combining with our continuous technological innovation and hard work, we believe that you will choose our company and keep a long-term business relationship with us!
