Lvhuan Power 500KW best natural gas generator prices for you WE DEVOTE OURSELVES TO GAS POWER GENERATION. 1. Company Introduction Since 2008 Factory area over 40000m2
2015 cheap price 400kw coal oven gas generator big power plant for steel palnt and coke oven plant LVHUAN POWER
Specifications
1, Coal Bed Methane gen-set
2. Advanced Control Panel
3. ISO9001-2008,ISO14001-2008, CE
4. Service OEM Offered
coal gas generator set
there are many methods to produce coal gas, such as coke oven gas, cola producer gas, semi-coke gas, water coal gas , iol coal gas, blast- furnace gas and cracking coal gas etc, the main compositions are CO, H2, N2, CO2, etc.
coke oven gas generator set
the producing method of coke oven gas is as below mentioned : raw coal is crushed and washed , after that, defferent coal will be mixed together with different ratio and put into furnace , and then it will produce coal gas and coal tar with high temperature pyrolysis in air-free condition.
coal bed gas instruction
Coal bed gas is a kind of burnable gas withour any color, taste and smell, it will explode if the concentration ranges at 5%-16%, and if oxygen larger than 12%, it will also explode when meets the naked light or temperature between 650 ºC to 750 ºC ,explosive power will be biggest if concertration is 9.5%, it was not explode if concertration larger than 16%, it was generated by coal or rotten plants and exist in two states: absorbing and dissociate, generation with coal bed gas do not only keep the mine safe but also remit the situation of lacking power .
Features of our coal power generator:
1.Pure copper water tank for best cooling effect
2.Famous component brand to ensure overall quality
3.Expansion fitting combined with shrinking fitting give high tightness to the system.
4.Safety guarantee form electromagnetic valve as well as back-fire relief valve
5.Residual heat CHP recycle system available for choice.
Machine supply details:
Ignition system:We adopt ignition system of magneto which produced by American ALTRONIC company,including:magneto,high-tension coil,sparking plug.
Starting system: DC24V electric motor,12v190 adopt ST710 of direct-current.
Pressure charging system:Pulse Mixed-flow supercharger, compression ration is 1:8,meet engine's requirement for gas-flow rate.
Speed regulating system: EGS gas controller of American WOODWARD Company.
Coal power generator work site requirements:
The work site needs to meet following basic requirements:
a) Ambient temperature between -40ºC~40ºC;
b) Relative humidity less than 95%(35ºC);
c) Site elevation not higher than 2500m;
d) For outdoor installation, simple rain shelter is required.
Core Features:
Manufacturer supply
Power supply range:1000kw
Continuous power supply range: 800kw
Standard component and assembly
Multi-option of control panel
With CE and ISO certificate
Parameter of Natural Gas Generator Set |
|
| Model Number (Engine Type) | LHNG500 |
| Brand Name | LVHUAN |
| Prime Power/Standby Power | 400KW/500KW |
| Rated Speed | 1000/1200RPM |
| Rated Frequency | 50/60Hz |
| Rated Voltage | 400V/230V |
| Phase | AC 3-Phase, 4 wire |
| Voltage Stability | ≤±2% |
| Voltage transient | ≤±10% |
| Voltage Stable time | ≤1s |
| Heat consumption | ≤11mj/kw.h |
| Lubricant Consumption | ≤1.0g/kw.h |
| Engine Capacity | 71.4L |
| Cylinder Number | 12-V |
| Cylinder Bore | 190mm |
| Stroke | 210mm |
| Starting System | DC 24V electric motor |
| Cooling method | water cooler |
| Lubricant method | Passive and flying lubricant |
| Isolation class | H |
| Protection | IP23 |
| Alternator | Siemens |
| Power Factor | 0.8 lagging |
| Exciting method | brushless |
| Colour | your choice |
| Certificates | ISO 9001:2008, CE |
| Warranty | 1 year or 1000 running hours which arrives first |
| Type | Open |
| Control system | Automatic alarm system |
| Size | 6200x2100x2800mm |
| Weight | 12500kg |
Shandong Lvhuan Power Equipment Co., Ltd. is a manufacturer which specially produces internal-combustion gas engine generator sets and gas engines, with registered capital of more than RMB10 million, annual turnover of RMB100 million, over 200 staff, beautiful scenery and convenient transportation. Our factory mainly specializes in the design, research, production, sale, installation and technical service of gas generator sets and diesel generator sets. Our company has strong specialty, powerful technical force, a complete production plant, advanced processing technology, mature inspection method and a strict test system.
Our products include 105, 135 and 190 series base engines. The output power ranges from 10kw to 500kw. The gensets can be used for biogas, natural gas, oil associated gas, coal mine gas and mash gas produced by burying rubbish and sewage disposal.
We manage our company by ISO9001 system strictly. Gas engines and alternators are environment-friendly products.
Our philosophy is "Only pay attention to supplying stronger power to you". More importantly, combining with our continuous technological innovation and hard work, we believe that you will choose our company and keep a long-term business relationship with us!
