Warranty:16 months
MOQ:100 sets
Delivery time:20-25days after received deposit
The quotation show as picture are common supplied,we can supply as per your specific requests.
Port of Shipment: NingBo, China
Terms of Payment:1. 30% T.T deposit in advance,the balance payment before delivery 2. L/C At Sight
Generator set |
Model |
WH3500I |
Rated frequency(Hz) |
50 |
Reted voltage(V) |
230 |
Reted output power(KVA) |
2.8 |
Max. output power(KVA) |
3 |
Rated rotation speed(rpm) |
3000 |
Total Harm onic Distortion(THD) |
<3.5%(typical) |
<5%(maximum) |
DC output |
12V 8A |
Power factor cos |
1 |
Phase number |
Single phase |
Noise level dB@7m(zeroload-fullload) |
70-72 |
Fuel tank(L) |
12L |
Over dimension(L*W*H)(mm) |
575*460*465 |
N.W/G.W(kg) |
35/36 |
Engine |
Engine model |
WG200 |
Engine type |
Single cylinder, 4-stroke, air-cooled, OHV, gasoline engine |
Displacement(cc) |
200 |
Compression ration |
8.5:1 |
Rated power(Hp/rpm) |
6.7/3600 |
Rated ratation speed(rpm) |
3600 |
T.C.I |
With |
Spark plug |
F6RTC |
Starting system |
Recoil starter |
Rotation direction(view from flywheel) |
Clockwise |
Fuel type |
Automotive unleaded gasoline |
Lube oil brand |
SAE10W30(above CC grade) |
Low oil alarm system |
With |
