Product Specifications
Spec Value
Item number 8SC3238VCB15
Sales number N/A
Series number 8SC/SCJ
Notes 2 GROOVE PULLEY PULLEY
System voltage 24
Output 100A
Dimensions in N/A
Rotation CLOCKWISE
Housing coating N/A
UL Approved No
Positive stud 5/16-24
Negative stud 1/4-28
Rectifier location INTEGRAL
Pulley included Yes
Availability
Region Priority / Status
Not currently available in the US or Europe. Contact us for additional information
Technical Bulletin
Title / Link Description
8SC-SCJ Maintenance Manual Maintenance manual for the 8SC SCJ series of alternators.
TSM1002_8SC-SCJ_Maintenance_Manual. Pdf (6.5 MB)
