The Biomass Genset/husk generator/alternator for power produce machinery
Power generation by using biomass gas from rice husk, wood chips, saw dust and crop stalks can not only save expenditure in electricity tariff in the production cost of rice mills and timber processing mills, but also can bring about benefits by means of selling surplus electric power to the power grid As the higher conversion efficiency of the equipment, by taking rice husk as an example, every kWh power generation consumes only 1.6~1.8kg of rice husk. If using wood dust or crop stalks as fuel, the unit consumption of the fuel will be still lower. Water used for gas cleaning and cooling can be used in a circulating way after it is treated through water treatment facilities such as a sediment pond without environmental pollution and with need only small amount of making up water.
|
The 1000KW HUSK GENERATOR QUOTATION LIST |
|
A: Generator system: |
|
Item |
Product Description |
Chart code |
Qty |
|
1 |
Gas engine |
8300D/M |
2 |
|
2 |
Engine hoisting tool |
300.90.1800 |
1 |
|
3 |
Coupler |
CRR2312 C1G2312R010 |
2 |
|
4 |
Generator(SIEMENS) |
1FC6 506-5LA42-Z |
2 |
|
5 |
Control cabinet beside engine |
JPX-02B |
2 |
|
6 |
Butterfly valve |
D71F-16C DN125 PN16 |
2 |
|
7 |
Spherical valve |
Q41F-16C DN125 PN16 |
2 |
|
8 |
Lube cooler |
BRO.23-15/Y |
2 |
|
9 |
Water cooler |
BRO.23-15/S |
2 |
|
10 |
Water temperature modulato |
LZFT-65 |
2 |
|
11 |
Lube oil temperature modulator |
LZFT-50 |
2 |
|
12 |
Suck oil pipe of lube oil pump |
|
12sets |
|
13 |
Out oil pipe of manual pump |
500GFW-BJ12Y-03001 |
2 |
|
14 |
Suck oil pipe of manual pump |
500GFW-BJ12Y-03003 |
2 |
|
15 |
Out oil pipe of manual pump |
500GFW-BJ12Y-03004A |
2 |
|
16 |
Pipe for water return to engine |
500GFW-BJ12Y-03005 |
2 |
|
17 |
Flexibility pipe of lube oil filter |
500GFW-BJ12Y-03010 |
2 |
|
18 |
Flexibility pipe of lube oil |
500GFW-BJ12Y-03011 |
2 |
|
19 |
Flexibility pipe of water |
500GFW-BJ12Y-03014 |
2 |
|
20 |
Flexibility oil pipe to engine |
500GFW-BJ12Y-03015 |
2 |
|
21 |
Bracket for cooler(left) |
500GFW-BJ12Y-03006( ) |
4 |
|
22 |
Bracket for cooler(right) |
500GFW-BJ12Y-03006( ) |
|
|
B: Gasification system |
|
Item |
Product Description |
Qty |
|
1 |
Fluidized bed Gasifier |
1 |
|
2 |
Flat Faced Swage |
1 |
|
3 |
Stock bin |
1 |
|
4 |
Ignitor |
2 |
|
5 |
Fuel tank |
1 |
|
6 |
Air distribution plate |
1 |
|
7 |
Ash release reducer |
1 |
|
8 |
Ash release screw shaft |
1 |
|
9 |
Ash release screw conveyor |
1 |
|
10 |
Air Tranportation System for Ash |
1 |
|
11 |
Induced Draft Fan |
1 |
|
12 |
Temperature sensor |
3 |
|
13 |
Control cabinet |
1 |
|
14 |
Pneumatic valve |
3 |
|
C: Wet cleaning system |
|
Item |
Product Description |
Qty |
|
1 |
Cyclone |
2 |
|
2 |
Pressure Regulator |
1 |
|
3 |
Liquid Seperator |
2 |
|
4 |
Water pump |
2 |
|
5 |
Spray Tower |
1 |
|
6 |
Bubble dust collector |
1 |
|
7 |
Cooling Tower |
1 |
|
8 |
Water pump |
2 |
|
9 |
Fan |
2 |
|
10 |
Roots Blower |
1 |
|
11 |
325 Tunnel |
30 |
|
12 |
325 Elbow |
15 |
|
13 |
325 Flange |
30 |
|
14 |
325 Asbestos pad |
15 |
|
15 |
80 Tunnel |
20 |
|
16 |
80Elbow |
6 |
|
17 |
80 Flange |
18 |
|
18 |
80 Asbestos pad |
9 |
|
19 |
Vibration-proof pressure gauge |
5 |
|
D: Toner collection system |
|
|
Product Description |
Qty |
|
1 |
919 Fan |
1 |
|
2 |
Ash screw valve |
2 |
|
3 |
Hopper bracket |
1 |
|
4 |
Hopper |
1 |
|
5 |
Butterfly valve |
2 |
|
6 |
Integrated cover |
1 |
|
7 |
Pulse dust collector |
1 |
|
8 |
Air compressor |
1 |
|
9 |
159 welded pipe |
40 |
|
10 |
159 Elbow |
6 |
|
11 |
159 Flange |
28 |
|
12 |
159 Asbestos pad |
14 |
|
E: Control and protection system |
|
Item |
Product Description |
Qty |
|
1 |
Gas analyzer(chose) |
1 |
|
2 |
Controlling Cabinet |
1 |
|
3 |
Anti-explosion Device |
1 |
|
4 |
Rapid cut-off valve |
1 |
|
5 |
Alarm |
1 |
|
6 |
Pressure transmitter |
2 |
|
7 |
Temperature sensor |
5 |
|
8 |
Motorised valve |
2 |
|
9 |
Shielded line |
100 |
Labay Located in An Ancient Town-Da Tang Town, ZhuJi City. Predecessor is ZhuJi Labay Machinery Factory. Especially for Manufacuting, import, export all kinds of high quality electromechanical Equipments Project, And agriculture machinery Project.
As one of the Production Configuration Trading Group, With Rich technology team and Service networks, Labay Always provide high quality products and best service. We always keeping our words, high quality and efficiency.
In Last many years' effort, Labay Already be Approbated by All our Customers. Quality, Service, Credit are our responsibility, We sincerely hope that through this opportunity can keep on and establish our long-term friendly cooperation.
