| GENSET MODEL | GDR75*S | |
| RATED OUTPUT(Kw) | 60kw | |
| MANUFACTURER | GODLIKE POwer | |
| RATED VOLTAGE(V) | 50HZ /400V 1500RPM | |
| RATED CURRENT(A) | 126 | |
| GENSET DIMENSIONS | 2800× 1040× 1450 | |
| WEIGHT(KGS) | 1100 | |
| ENGINE | TYPE | R6105ZD |
| MANUFCRURER | Weifang | |
| 12H POWER (KW) | 84 | |
| FUEL CONSUMPTION | ≤ 231 | |
| STARTING TYPE | Electric starting/DC24V | |
| BORE× STROKE | 105x125 | |
| CYLINDER NUMBERS | water cooled, in line, 6-cylinders 4-cycle, direct injection | |
| ALTERNATOR | TYPE | Copy stamford --JDG224 |
| RATED POWER(KVA) | 85 | |
| MAX POWER(KVA) | 93.5 | |
| POWER FACTOR | 0.8 | |
| EXCITATION MODE | SAE , Brushless sychronous , Three harmonic exciting | |
| AVR MODEL | SX460 | |
| INSULATION CLASS | CLASS H | |
| IP LEVEL (PROTECTION) | IP21-23 | |
| CONFIGURATION TYPE | IMB35 With frange, 2/3 pitch design | |
| DIMENSION(mm) | 960× 550× 810 | |
| WEIGHT (KGS) | 350 | |
| 50HZ, 3 Phase, 400/230V | ||||||||||
| No. | GENSET Model | OUTPUT POWER 1500RPM 50HZ | Engine Model | Alternator Model | Cyl. | Fuel Cons. | ||||
| Prime KVA | Prime KW | Standby KVA | standby KW | HUAFENG | GODLIKE | STAMFORD | (nos) | (lir/hr) | ||
| 1 | GDH28*S | 28 | 22 | 30 | 24 | K4100D-1 | JDG184E | BCI184E | 4L | 5.8 |
| 2 | GDH31*S | 31 | 25 | 34 | 28 | K4102D1-1 | JDG184F | BCI184F | 4L | 6.2 |
| 3 | GDH43*S | 43 | 34 | 47 | 37 | K4100ZD1 | JDG184G | BCI184G | 4L | 8.7 |
| 4 | GDH60*S | 60 | 48 | 66 | 53 | R4105ZD1-1 | JDG184H | BCI184H | 4L | 12.5 |
| 5 | GDH69*S | 69 | 55 | 76 | 61 | R4105IZLD-1 | JDG224C | UCI224C | 6L | 14.1 |
| 6 | GDH88*S | 88 | 70 | 96 | 77 | R6105ZD1-1 | JDG224D | UCI224D | 6L | 18.3 |
| 7 | GDH100*S | 100 | 80 | 110 | 88 | R6105ZLD-1 | JDG224ES | UCI224E | 6L | 21 |
| 8 | GDH113*S | 113 | 90 | 124 | 99 | R6105AZLD-1 | JDG224E | UCI224E | 6L | 23.3 |
| 9 | GDH138*S | 138 | 110 | 151 | 121 | R6105IZLD | JDG224F | UCI224F | 6L | 28.7 |
| 10 | GDH160*S | 160 | 128 | 176 | 141 | R6113ZLD1-1 | JDG224G | UCI224G | 6L | 33.2 |
Contact: Ms Vicki Yuan| Prod Model: | GDR75*S |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Specialize: | 100% Famous Material |
| Engine: | China Famous Brand, Cummins, Perkins, Deutz |
| Alternator: | Stamford, Marathon, Engga, Godlike |
| Controller System: | Micro-Computer Control Automatic or Mechanical |
| Type: | Basic Diesel Generator |
| Installation Method: | Fixed |
| Stroke: | Four Stroke |
| Cooling Method: | Wind Cooling |
| Output Type: | AC Three Phase |
