| Price: | US $ 86-89/Set |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 240/Set |
| Pay Type: | L/C,T/T,Western Union |
| Generator | Rated Frequency (Hz) | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 |
| Rated Voltage(V) | 110/120/220/230/240 | ||||||||||||
| Rated Power Output(kVA) | 2 | 2.5 | 2.5 | 2.7 | 2.8 | 3.6 | 4 | 4.5 | 5 | 5.5 | 6 | 6.5 | |
| The Max.Power Output(kVA ) | 2.2 | 2.7 | 2.7 | 3 | 3 | 4.2 | 4.8 | 5 | 5.5 | 6 | 6.5 | 7 | |
| Power Factor(cos φ ) | 0.8/1 | ||||||||||||
| Engine | Type | 168F-1 | 170F | 170F | 188F | 188F | 190F | ||||||
| Model | 6.5HP | 7.0HP | 7.0HP | 13.0HP | 13.0HP | 15.0HP | |||||||
| Category | Single cylinder,air-cooled ,four stroke ,OHV gasoline engine | ||||||||||||
| Exclusion of Cylinder(cm³) | 196 | 210 | 210 | 389 | 389 | 407 | |||||||
| The Max.output Power (kW/rpm) | 4.8/3600 | 5.7/3600 | 5.7/3600 | 9.5/3600 | 9.5/3600 | 11.0/3600 | |||||||
| Ignition System | Transistorized magneto | ||||||||||||
| Start System | Recoil (Hand start / Manual ) or Electric start with battery is optional | ||||||||||||
| Capacity of Fuel Tank(L) | 15 | 15 | 15 | 25 | 25 | 25 | |||||||
| Consumption of Fuel(L/h) | 1.32 | 1.38 | 1.38 | 2.45 | 2.7 | 2.95 | |||||||
| Consecutive Working(h) | 13 | 11 | 11 | 10 | 9 | 8 | |||||||
| Noise(at7m((dB) | 68 | 72 | |||||||||||
| Capacity of Engine Oil(L) | 0.6L | 1L | |||||||||||
| Dimension | Set Dimension(LXWXH)mm | 615X435X455 | 670X510X510 | 692X522X545 | |||||||||
| Net Weight(kg) | 40 | 42 | 43 | 78 | 80 | 85 | |||||||
| Standard Equipment | Large capacity fuel tank ,large capacity muffler,fuel gauge ,voltmeter,AVR,oil alert ,AC circuit breaker | ||||||||||||
| Purchasing | Four-wheel dolly kit | Yes | |||||||||||
1.Q:What is the Quality Warranty for the products?
A:We offer 1 year quality warranty for all of our products.
2.Q:Where is your factory located? How can I visit there?
A: Our factory is located in Taizhou City, Zhejiang Province, China, about 2 hours train from Shanghai . All our clients, from home or abroad, are warmly welcome to visit us!
3.Q:What is the material of your products?
A: Only New material can be used for our products.
Materials for Generator: 100% Pure Crankcase, 100% Pure Copper Wire
Materials for Water Pump: 100% Pure Auminium Pump body and Crankcase
4.Q:What is Minimum Order quantity?
A: MOQ 50/100 pieces for different products.
You are welcomed to consult for details.
5.Q:How does your factory do regarding quality control?
A: From the internal parts to the outside packing, we not only make standard quality test,but also think ahead for a better solution. Except company QC system, We have achieved CE & SONCAP certificate.
| Prod Model: | Generating Sets ASTRA KOREA 3700 |
|---|---|
| Markets: | South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Generator Fuel: | Gasoline (Petrol) |
| Power Output Coule Be Customer Made: | 1.5kVA to 7kVA Is Optional |
| Alternator: | Aluminium or Copper Is Optional |
| Application: | Home Use,Outdoor,Store Lighting ,Construction |
| Advantage: | Low Noise & Oil Consumption ,Steady Working |
| Whole Machine Design: | Simple ,Practical ,Easy & Fast to Operate |
| Reliable & Compact Structure Ohv Engine: | Economic Fuel Consumtion ,Low Displacement |
| Large Capacity Fuel Tank: | 15L ,Providing Long-Lasting Energy Power Output |
| Automatic Voltage Regulation(AVR): | Keep Electricity Sustained and Steady |
| Circuit Breaker: | with |
| Output Type: | AC Single Phase |
