Genset power: 36KW-64KW
Voltage: 110V/220V/380V/400V/440V/480V, 50/60Hz, 0.8 lagging, 3 phase 4 wires
Certificate: ISO9001, ISO14000, CE, SONCAP, etc.
Warranty: 1 year/1000hr
Soundproof canopy 75dbA@7m
Self-excitation system, high quality diesel engine and alternator, low fuel consumption, strong maintenances, easy operation.
Engine specification:
Engine: UK Perkins
Engine type: Diesel, water cooled, 4 stroke, direct injection.
Alternator specification:
Alternator: Leroy somer, Stamford, Marathon and others
Alternator type: Brushless alternator, single bearing, flange connection, IP23, H insulation class, with AVR
Supply Scope:
1. Standrad tool kits and complete operation/maintenance/spare parts manuals to Engine/Alternator
2. Brand-new engine, w/ start motor.
3. Brand new brushless alternator, single bearing, flange connection, IP23, H insulation class, with AVR.
4. Auto control panel, with LCD display.
5. Engine mounted battery-charging alternator, Genset with battery charger of mains supply.
5. Circuit Breaker, Exhaust Silencer
6. Radiator for 40-50 ambient temperature and bouble-deck cooling, with fan guard and front guard
7. Anti-vibration pads are fixed between engine/alternator and base frame, as to ensure the compete genset running under stabilization.
8. Skid-mounted bottom Fuel tank - 8hrs continuous running(bigger fuel tank by your demand under extra cost)
9. External recessed emergency stop button for extra safety
10. The colors & Brands by your requests
11. Optional Choice: Soundproof, ATS (automatic transfer switch), AMF panel, Trailer, Parallel system by your extra choose.
Genset
Model
| Prime power
(KVA)
| Standby power
(kw)
| Engine model
| Fuel
consumption (L/H)
| Open Genset
Dimension (mm)
|
AP10-II
| 9/10
| 7/7.7
| 403A-11G1
| 3.0
| 1088x449x891
|
AP50
| 45/50
| 36/40
| 1103A-33TG1
| 10.7
| 1493x634x1166
|
AP110-I
| 100/110
| 80/88
| 1006TG2A
| 21.8
| 2300x800x1400
|
AP149
| 135/149
| 108/118
| 1006-6TAG
| 31.0
| 2196x773x1375
|
Genset
Model
| Prime power
(KVA)
| Standby power
(kw)
| Engine model
| Fuel
consumption (L/H)
| Open Genset
Dimension (mm)
|
AP440
| 400/440
| 320/352
| 2206C-E13TAG3
| 81
| 3000x1120x1946
|
AP1100
| 1000/1100
| 800/880
| 4008TAG2A
| 220.0
| 4582x2050x2500
|
AP1650-I
| 1500/1650
| 1200/1320
| 4012-46TAG2A
| 281.0
| 4762x2160x2509
|
AP2137
| 1710/2137
| 1368/1504
| 4012-46TAG3A
| 380.6
| 5600x2100x2500
|
We, Xiamen AOSIF Engineering Ltd is one of generator manufacturers founded in 2001, we dedicated ourselves to the production, R & D and maintenance of various diesel generator sets, electrical control systems, and related accessories like soundproof canopy, Trailer, ect.
We always submit ourselves to cooperate with international and domestic manufactures of diesel engine and have earned good recognition and reputation from our customers due to our quality orientation under ISO9001, ISO14001, CE, SGS, Soncap Certifications and OEM Partners of Cummins, Wandi, Jichai and Leroy-somer as well, which were certified one after another since 2003.
Nowadays we have our own registered trademark "AOSIF" to be well known of all customers worldwide who have always been in business on power, and our generator sets have been exported to more than 50 countries, which focus on Asian, European, African and American. Our mission is to advance our scientific management, to improve our quality level constantly and to maximum customers' profitability.
We have manufactured many kinds of products as below,
Engine brand: Cummins, Perkins, Deutz, Doosan, Volvo, Johndeere, Man, Mitsubishi, Lovol, and Chinese local brands etc...
Alternator brand: Leroy somer, Stamford, Marathon
Power range: 5kVA-5000kVA
Delivery time: 15 to 30 days.
Quality Warranty Period: 1 year or 1000hours whichever comes first
Customers satisfaction is the aim of our team!
